Taiwan Commate Computer Inc. PV-DDR User Manual page 41

3.8.1 Shutdown Temperature
This function will be effective only for the operation systems that support
ACPI function. System can monitor CPU temperature, if temperature is
over the setting value system will automatically power off.
3.8.2 Vcore, Vcmos, Vcc3, Vcc, +12V, 5VSB & VBAT (xx.xxV)
The onboard hardware monitor is able to detect the voltage output by the
voltage regulators. These values refresh upon any key entry.
3.8.3 CPU & System Temperature (xx°C/xx°F)
The onboard hardware monitor is able to detect the temperatures of
motherboard and CPU. These values refresh upon any key entry.
3.8.4 CPUFAN & SYSFAN Speed (xxxxRPM)
The onboard hardware monitor is able to detect system fan speed, CPU
fan speed in Rotations Per Minute (RPM). These values refresh upon any
key entry in the BIOS setup screen.
3.9 Frequency Control
CMOS Setup Utility - Copyright ( C ) 1984 - 2000 Award Software
CPU Host/PCI Clock
Exit F1 : General Help
Optimized Defaults
3.9.1 CPU Host/PCI Clock
The field can select CPU Host/PCI Clock. Note that selecting a frequency
higher than the CPU manufacturer recommends may cause the system to
hang or crash.
Figure 3.9 Frequency Control
Frequency Control
[Default]
¯ ® ¬: Move
Enter : Select
F5 : Previous Value
Item Help
Menu Level >
+/-/PU/PD : Value F10 : Save ESC :
F6 : Fail-Safe Defaults F7 :
