Taiwan Commate Computer Inc. PV-DDR User Manual page 11

2.3.3 Memory Configuration
There is no jumper setting required for the memory size or type. It is
automatically detected by the system BIOS, and the total memory size is to add
them together.
DIMM Socket
DIMM1
DIMM2
DIMM3
DIMM4
2.4 I/O Connections/Panel Connections
I/O Connections
ATXPWR
CPUFAN
SYSFAN
JIR
WOL1
WOM1
FDD
IDE1, 2
PS_KB
COM1, 2
LPT
USB1, JUSB1/2
GAME
LINOUT
LININ
MIC
JCDIN1
2.4.1 ATX Power Connector (20-pin ATXPWR)
Make sure that the power supply is off before connecting or disconnecting the
power cable.
PC1600/2100 DDR SDRAM 64, 128, 256, 512MB, 1GB
PC1600/2100 DDR SDRAM 64, 128, 256, 512MB, 1GB
PC1600/2100 DDR SDRAM 64, 128, 256, 512MB, 1GB
PC1600/2100 DDR SDRAM 64, 128, 256, 512MB, 1GB
ATX Power Connector
CPU fan connector
System fan connector
Infrared Connector ( Cable optional )
Wake On LAN connector
Wake On Modem connector
Floppy Disk Drive Connector
Primary/ Secondary IDE Connectors
PS/2 Mouse Port & Keyboard Connector
Serial Ports 1 & 2
Printer Port
USB Connector ( Cable optional )
Game/MIDI Connectors
Line out Connector
Line in Connector
Microphone in Connector
The Connector for IDE/Sony CD-ROM audio
cable
DIMM Modules
