Troubleshooting; Technical Specifications - Transition Networks CFMFF1314-280 User Manual

CFMFF13xx-28x
Cable Specifications -- continued
CFMFF3535-280, Ports 1 & 2
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFMFF1414-280, Port 2
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:

Technical Specifications

For use with Transition Networks Model CFMFF13xx-28x or equivalent
Standards: IEEE 802.3™ 2000 (802.3z)
Dimensions: 3.4" x 0.86" x 5.0" (86 mm x 22mm x 127mm)
Weight 5 oz (141 g) (approximate)
Data Rate 1000 Mb/s
Delay Time 184 ns
Power Consumption 3.6 watts (typical)
Environment Tmra*:
Storage Temp:
Humidity:
Altitude:
Warranty Lifetime
*Manufacturer's rated ambient temperature: Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will be
installed.
NOTE: Information in this user's guide is subject to change. For the most up-to-
date information on the CFMFF13xx-28x media converter, view the user's guide
on-line at: www.transition.com
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into
beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.
The fiber optic transmitters on this device meet Class I Laser safety requirements
per IEC-825/CDRH standards and complies with 21 CFR1040.10 and
21CFR1040.11.
8
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
1550 nm single mode
min: 0.0 dBm max: +5.0 dBm
min: -27.0 dBm max: -3.0 dBm
27.0 db
1310 nm single mode
min: -13.0 dBm max: -3.0 dBm
min: -20.0 dBm max: -3.0 dBm
7.0 dB
0°C to 50°C (32°F to 122°F)
-15°C to 65°C (5°F to 149°F)
5 to 95%, non condensing
0 to 10,000 feet

Troubleshooting

If the media converter fails, isolate and correct the fault by determining the
answers to the following questions and then taking the indicated action:
1. Is the PWR (power) LED illuminated?
NO
• Is the media converter inserted properly into the chassis?
• Is the power cord properly installed in the chassis and at the external
power source?
• Does the external power source provide power?
• Contact Technical Support. US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Are the Auto-Negotiation switches on the network devices set
such that all are set to "enable" or all are set to "disable"?
NO
• Set the Auto-Negotiation switches on all of the devices (including the
end devices) so that all are set to "enable" or all are set to "disable."
(See page 3 to set the Auto-Negotiation switch on the media
converter.)
• Contact Technical Support. US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the LKS (link, single mode) LED illuminated?
NO
• Check the single mode fiber cables for proper connection.
• Verify that the TX and RX cables on the media converter are
connected to the RX and TX ports, respectively, on the other device.
• Contact Technical Support. US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 4.
4. Is the LKM (link, multimode) LED illuminated?
NO
• Check the multimode fiber cables for proper connection.
• Verify that the TX and RX cables on the media converter are
connected to the RX and TX ports, respectively, on the other device.
• Contact Technical Support. US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 5.
