CAPTF33xx-1xx
RJ-11C Connector Specification
Unit A (Telephone Emulation)
Connector: RJ-11C
600 Ω
Impedance:
REN: 0.4 B
Loop Current: 10 to 100 mA
Insertion Loss: 0.0 ± 1.0 dB at 1000 Hz
(When both ports are terminated at 600 Ω.)
Unit B (Central Office Emulation)
Connector: RJ-11C
600 Ω
Impedance:
Battery Source: 48 VDC +/- 5V
Ringing Supply: 90 Vp-p
RIng Frequency: 15-30 Hz (Reproduces the frequency detected by Unit A.)
Ring Cadence: Reproduces the cadence detected by Unit A.
Insertion Loss: 0.0 ± 1.0 dB at 1000 Hz
(When both ports are terminated at 600 Ω.)

Technical Specification

For use with Transition Networks Model CAPTF33xx-1xx or equivalent
Standards FCC Part 68, TBR21
Dimensions 3.4" x 5.0" x 1.75" (86 mm x 182 mm x 43 mm)
Weight 6 oz. (0.181 g) (approximate)
Power Consumption 7.0 watts
MTBF 341,000 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
888,000 hours (Bellcore7 V5.0)
Environment Tmra*:
Storage Temp:
Humidity:
Altitude:
Warranty Lifetime
*Manufacturer's rated ambient temperature. Tmra range for this slide-in-module depends
on the physical characteristics and the installation configuration of the Transition Networks
PointSystem™ chassis in which this slide-in-module will be installed.
The information in this user's guide is subject to change. For the most up-to-date
information on the CAPTF33xx-1xx media converter, view the user's guide on-line at:
www.transition.com.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR, Subchapter J
applicable at the date of manufacture.
CAUTION: Visible and Invisible Laser Radiation When Open. Do Not Stare Into Beam Or
View Directly With Optical Instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other than
those specified herein may result in hazardous radiation exposure.
12
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
0° to 50°C (32° to 122° F )
-15° to 65°C (-4° to 122°F)
5 to 95%, non condensing
0 to 10,000 feet

Troubleshooting

1. Is the PWR (power) LED illuminated?
NO
• Is the media converter slide-in-module installed properly in the
chassis?
• Is the power cord properly installed in the chassis and at the external
power source?
• Does the external power source provide power?
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the SDF (signal detect fiber Link) LED illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the first media converter are
connected to the RX and TX ports, respectively, on the second media
converter.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the ACT (active) LED illuminated?
NO
• Ensure that the local unit is off-hook.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
techsupport@transition.com Click the "Transition Now" link for a live Web chat. 13
