CAPTF33xx-1xx
Unit A - CAPTF33xx-100
Unit A (CAPTF33xx-100) connects to a Central Office (CO) telephone line or a
PBX (Private Branch Exchange). It mimics a telephone device (Line-Side FXS) and
has the ability to detect ringing voltages. The available models are:
Product Number Port One - Copper
Twisted-Pair
CAPTF3311-100 RJ-11C connector
5 km (3.1 miles)*
CAPTF3313-100 RJ-11C connector
5 km (3.1 miles)*
CAPTF3314-100 RJ-11C connector
5 km (3.1 miles)*
CAPTF3315-100 RJ-11C connector
5 km (3.1 miles)*
Unit A is also available in single mode, single fiber models.
Product Number Port One - Copper
Twisted-Pair
CAPTF3329-100 RJ-11C connector
5 km (3.1 miles)*
CAPTF3329-101 RJ-11C connector
5 km (3.1 miles)*
CAPTF3329-102 RJ-11C connector
5 km (3.1 miles)*
CAPTF3329-103 RJ-11C connector
5 km (3.1 miles)*
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network installation.
The single mode, single fiber models are designed to be installed in pairs.
The table below lists which models should be installed in the same
network for the standard configuration (see page 4).:
If this model is installed as Unit A:
CAPTF3329-100
CAPTF3329-101
CAPTF3329-102
CAPTF3329-103
2
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Port Two - Duplex Fiber-Optic
ST connector, 1300 nm multimode
2 km (1.2 miles)*
SC connector, 1300 nm multimode
2 km (1.2 miles)*
SC connector, 1310 nm single mode
20 km (12.4 miles)*
SC connector, 1310 nm single mode
40 km (24.9 miles)*
Port Two - Fiber-Optic
Single Mode, Single Fiber
SC, 1310 nm (TX) / 1550 nm (RX),
20 km (12.4 miles)*
SC, 1550 nm (TX) / 1310 nm (RX),
20 km (12.4 miles)*
SC, 1310 nm (TX) / 1550 nm (RX),
40 km (24.9 miles)*
SC, 1550 nm (TX) / 1310 nm (RX),
40 km (24.9 miles)*
Install this model as Unit B:
CAPTF3329-111
CAPTF3329-110
CAPTF3329-113
CAPTF3329-112
Unit B - CAPTF33xx-110
Unit B (CAPTF33xx-110), the reciprocal unit to unit A, connects to a telephone
device and mimics a Central Office (Customer-Side FXO). The available models
are:
Product Number Port One - Copper
Twisted-Pair
CAPTF3311-110 RJ-11C connector
5 km (3.1 miles)*
CAPTF3313-110 RJ-11C connector
5 km (3.1 miles)*
CAPTF3314-110 RJ-11C connector
5 km (3.1 miles)*
CAPTF3315-110 RJ-11C connector
5 km (3.1 miles)*
Unit B is also available in single mode, single fiber models.
Product Number Port One - Copper
Twisted-Pair
CAPTF3329-110 RJ-11C connector
5 km (3.1 miles)*
CAPTF3329-111 RJ-11C connector
5 km (3.1 miles)*
CAPTF3329-112 RJ-11C connector
5 km (3.1 miles)*
CAPTF3329-113 RJ-11C connector
5 km (3.1 miles)*
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network installation.
The single mode, single fiber models are designed to be installed in pairs. The
table below lists which models should be installed in the same network for the
automatic ring-down configuration (see page 4).:
If this model is installed as Unit B:
CAPTF3329-110
CAPTF3329-111
CAPTF3329-112
CAPTF3329-113
techsupport@transition.com Click the "Transition Now" link for a live Web chat.
Port Two - Duplex Fiber-Optic
ST connector, 1300 nm multimode
2 km (1.2 miles)*
SC connector, 1300 nm multimode
2 km (1.2 miles)*
SC connector, 1310 nm single mode
20 km (12.4 miles)*
SC connector, 1310 nm single mode
40 km (24.9 miles)*
Port Two - Fiber-Optic
Single Mode, Single Fiber
SC, 1310 nm (TX) / 1550 nm (RX),
20 km (12.4 miles)*
SC, 1550 nm (TX) / 1310 nm (RX),
20 km (12.4 miles)*
SC, 1310 nm (TX) / 1550 nm (RX),
40 km (24.9 miles)*
SC, 1550 nm (TX) / 1310 nm (RX),
40 km (24.9 miles)*
Install this model as the other Unit B:
CAPTF3329-111
CAPTF3329-110
CAPTF3329-113
CAPTF3329-112
