VLT® Flow Drive FC 111
Design Guide
Parameter Range
Parameter 1-46 20–200%
Position Detec-
tion Gain
20–200%
Parameter 1-48
Current at Min
Inductance for
d-axis
20–200%
Parameter 1-49
Current at Min
Inductance for
q-axis
Parameter 1-70
[0] Rotor Detection
PM Start Mode
[1] Parking
[3] Rotor Last Position
Parameter 1-73
[0] Disabled
Flying Start
[1] Enabled
Parameter 3-41 0.05–3600.0 s
Ramp 1 Ramp
Up Time
0.05–3600.0 s
Parameter 3-42
Ramp 1 Ramp
Down Time
Parameter 4-12 0.0–400.0 Hz
Motor Speed
Low Limit [Hz]
0.0–400.0 Hz
Parameter 4-14
Motor Speed
High Limit [Hz]
Parameter 4-19 0.0–400.0 Hz
Max Output
Frequency
Parameter
[0] Off
30-22 Locked
[1] On
Rotor Detection
0.05–1.00 s
Parameter
30-23 Locked
Rotor Detection
Time [s]
7.2.2.6 Changes Made Function
The changes made function lists all parameters changed from default settings.
Danfoss A/S © 2021.04
Default Usage
100% Adjusts the height of the test pulse during position detec-
tion at start.
Enter the inductance saturation point.
100%
This parameter specifies the saturation curve of the d- and q-
100%
inductance values. From 20–100% of this parameter, the in-
ductances are linearly approximated due to parameter 1-37
d-axis Inductance (Ld), parameter 1-38 q-axis Inductance (Lq),
parameter 1-44 d-axis Inductance Sat. (LdSat), and parameter
1-45 q-axis Inductance Sat. (LqSat).
Select the PM motor start mode.
[1] Parking
[0] Disabled Select [1] Enabled to enable the drive to catch a spinning mo-
tor.
Size related Ramp-up time from 0 to rated parameter 1-23 Motor Frequen-
cy.
Size related
Ramp-down time from rated parameter 1-23 Motor Frequency
to 0.
0.0 Hz Enter the minimum limit for low speed.
Enter the maximum limit for high speed.
100.0 Hz
100.0 Hz Enter the maximum output frequency value. If parameter
4-19 Max Output Frequency is set lower than parameter 4-14
Motor Speed High Limit [Hz], parameter 4-14 Motor Speed High
Limit [Hz] is set equal to parameter 4-19 Max Output Frequen-
cy automatically.
[0] Off –
–
0.10 s
Programming
AJ363928382091en-000101 / 130R0983 | 97
