3.1.1.4 Example with Varying Flow over 1 Year
This example is calculated based on pump characteristics obtained from a pump datasheet. The result obtained shows energy sav-
ings of more than 50% at the given flow distribution over a year. The payback period depends on the price per kWh and the price of
drive. In this example, it is less than a year when compared with valves and constant speed.
