VLT® Flow Drive FC 111
Design Guide
Coil 0
11 Data not valid
12 Relay 1 off
13 Relay 2 off
14 Set up LSB
15 –
16 No reversing
8.8.8.4 Drive Status Word (FC Profile)
Table 65: Drive Status Word (FC Profile)
Coil 0
33 Control not ready
34 Drive not ready
35 Coast stop
36 No alarm
37 Not used
38 Not used
39 Not used
40 No warning
41 Not at reference
42 Hand mode
43 Out of frequency range
44 Stopped
45 Not used
46 No voltage warning
47 Not in current limit
48 No thermal warning
8.8.8.5 Address/Registers
Table 66: Address/Registers
Bus ad- Bus PLC reg-
dress regis- ister
ter
(1)
0 1 40001
1 2 40002
2 3 40003
Danfoss A/S © 2021.04
Content Access
Reserved –
Reserved –
Reserved –
RS485 Installation and Set-up
1
Data valid
Relay 1 on
Relay 2 on
Reversing
1
Control ready
Drive ready
Safety closed
Alarm
Not used
Not used
Not used
Warning
At reference
Auto mode
In frequency range
Running
Not used
Voltage warning
Current limit
Thermal warning
Description
Reserved for legacy drives VLT® 5000 and VLT® 2800.
Reserved for legacy drives VLT® 5000 and VLT® 2800.
Reserved for legacy drives VLT® 5000 and VLT® 2800.
AJ363928382091en-000101 / 130R0983 | 115
