VLT® Flow Drive FC 111
Design Guide
Parameter Range
Parameter 6-29
[0] Current
Terminal 54
[1] Voltage
mode
Parameter
[0] Normal
20-81 PI Nor-
[1] Inverse
mal/Inverse
Control
0–200 Hz
Parameter
20-83 PI Start
Speed [Hz]
0.00–10.00
Parameter
20-93 PI Propor-
tional Gain
Parameter 0.1–999.0 s
20-94 PI Inte-
gral Time
Parameter
[0] Off
30-22 Locked
[1] On
Rotor Detection
0.05–1.00 s
Parameter
30-23 Locked
Rotor Detection
Time [s]
7.2.2.5 Motor Setup
The motor setup wizard guides users through the needed motor parameters.
Table 48: Motor Setup Wizard Settings
Parameter Range
Parameter 0-03
[0] International
Regional Set-
[1] US
tings
Parameter 0-06
[10] 380–440 V/50 Hz/IT-grid
GridType
[11] 380–440 V/50 Hz/Delta
[12] 380–440 V/50 Hz
[20] 440–480 V/50 Hz/IT-grid
[21] 440–480 V/50 Hz/Delta
[22] 440–480 V/50 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
Parameter 1-10
*[0] Asynchron
Motor Con-
[1] PM, non-salient SPM
struction
[3] PM, salient IPM
94 | Danfoss A/S © 2021.04
Default Usage
[1] Voltage Select if terminal 54 is used for current or voltage input.
[0] Normal Select [0] Normal to set the process control to increase the
output speed when the process error is positive. Select [1] In-
verse to reduce the output speed.
Enter the motor speed to be attained as a start signal for
0 Hz
commencement of PI control.
Enter the process controller proportional gain. Quick control
0.01
is obtained at high amplification. However, if amplification is
too high, the process may become unstable.
999.0 s Enter the process controller integral time. Obtain quick con-
trol through a short integral time, though if the integral time
is too short, the process becomes unstable. An excessively
long integral time disables the integral action.
[0] Off –
–
0.10 s
Default Usage
–
[0] Interna-
tional
Size selected Select the operating mode for restart after reconnection of
the drive to mains voltage after power down.
[0] Asynchron
Setting the parameter value might change these parame-
ters:
Programming
