VLT® Flow Drive FC 111
Design Guide
To define how bit 13 gates with the corresponding function on the digital inputs, use parameter 8-55 Set-up Select.
8.11.2.14 Bit 15, Reverse
Bit 15 = 0: No reversing.
Bit 15 = 1: Reversing. In the default setting, reversing is set to [0] Digital input in parameter 8-54 Reversing Select. Bit 15 causes revers-
ing only when [1] Bus, [2] Logic AND or [3] Logic OR is selected.
8.11.3 Status Word According to FC Profile (STW)
Set parameter 8-30 Protocol to [0] FC.
Follower-master
STW
Bit
no.: 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Illustration 79: Status Word
Table 87: Status Word According to FC Profile
Bit Bit = 0
00 Control not ready
01 Drive not ready
02 Coasting
03 No error
04 No error
05 Reserved
06 No error
07 No warning
08 Speed≠reference
09 Local operation
10 Out of frequency limit
11 No operation
12 Drive OK
13 Voltage OK
14 Torque OK
15 Timer OK
8.11.4 Explanation of Each Status Bit
8.11.4.1 Bit 00, Control Not Ready/Ready
Bit 00=0: The drive trips.
Bit 00=1: The drive controls are ready but the power component does not necessarily receive any supply (if there is 24 V external
supply to controls).
128 | Danfoss A/S © 2021.04
N O T I C E
Output freq.
RS485 Installation and Set-up
Bit = 1
Control ready
Drive ready
Enable
Trip
Error (no trip)
–
Triplock
Warning
Speed=reference
Bus control
Frequency limit OK
In operation
Stopped, auto start
Voltage exceeded
Torque exceeded
Timer exceeded
AJ363928382091en-000101 / 130R0983
