When the generic (conducted) emission standards are used, the drives are required to comply with the limits in the following table.
Table 8: Correlation between Generic Emission Standards and EN 55011
Environment
First environment (home and office)
Second environment (industrial envi-
ronment)
3.4.3 EMC Emission Test Results
The following test results have been obtained using a system with a drive, a shielded control cable, a control box with potentiome-
ter, and a shielded motor cable.
Table 9: EMC Emission Test Results, H1–H8
RFI filter Conduct emission. Maximum shielded cable length [m (ft)]
type
Industrial environment
EN 55011 Class A Group 2
Industrial environ-
ment
EN/IEC Category C3
61800-3
Second environment
industrial
Without
external
filter
H4 RFI filter (EN55011 A1, EN/IEC61800-3 C2)
0.37–22 kW –
(0.5–30 hp)
3x380–480
V IP20
H2 RFI filter (EN 55011 A2, EN/IEC 61800-3 C3)
30–90 kW 25 (82)
(40–125
hp) 3x380–
480 V IP20
H3 RFI filter (EN55011 A1/B, EN/IEC 61800-3 C2/C1)
30–90 kW –
(40–125
hp) 3x380–
480 V IP20
