VLT® Flow Drive FC 111
Design Guide
315 (450)
Table 39: H13–H14 Power/semiconductor Fuse Options, 380–480 V
Model Fuse Options
Bussman Littelfuse
P110 170M2619 LA50QS300-4
P132 170M2620 LA50QS350-4
P160 170M2621 LA50QS400-4
P200 170M4015 LA50QS500-4
P250 170M4016 LA50QS600-4
P315 170M4017 LA50QS800-4
6.10 Control Terminals
Remove the terminal cover (H1-H8) or the cradle cover (H13-H14) to access the control terminals.
H1-H8
Use a flat-edged screwdriver to push down the lock lever of the terminal cover under the LCP, then remove the terminal cover as
shown in Illustration 55.
Illustration 55: Removing the Terminal Cover
H13-H14
Press the tips of the cradle cover inwards as shown in
Danfoss A/S © 2021.04
Littelfuse Bussman Siba
L50S-300 FWH-300A 20 189 20.315
L50S-350 FWH-350A 20 189 20.350
L50S-400 FWH-400A 20 189 20.400
L50S-500 FWH-500A 20 189 20.550
L50S-600 FWH-600A 20 189 20.630
L50S-800 FWH-800A 20 189 20.800
Illustration 56, and then lift the cradle cover up.
–
Ferraz-Shawmut Ferraz-Shawmut(Europe)
A50QS300-4 6,9URD31D08A0315
A50QS350-4 6,9URD31D08A0350
A50QS400-4 6,9URD31D08A0400
A50QS500-4 6,9URD31D08A0550
A50QS600-4 6,9URD31D08A0630
A50QS800-4 6,9URD32D08A0800
AJ363928382091en-000101 / 130R0983 | 75
Electrical Installation
Considerations
aR-800
