2.0. ACR350 Hardware Overview

2.1. Parts of the Reader

1a 1b 1c 1d
2 3 4 5
6
7
8
ACR350 Validator with QR Code Scanner – User Manual
Version 1.02

Figure 1: ACR350 Parts

Part Number Part Name
1a, 1b, 1c,1d Programmable Button with Backlight (Blue)
2 Blue LED Indicator (For passenger)
3 Yellow LED Indicator (For passenger)
4 Green LED Indicator (For passenger)
5 Red LED Indicator (For passenger)
6 LCD Display with Touch Panel
7 Tapping Area
8 1D/2D Barcode Scanning Area
9 Speaker
10 Green LED Indicator (For Driver)
11 Red LED Indicator (For Driver)
12 Buzzer
13 Power Button
14 SIM and SD Card Cover
15 Back Cover

Table 1: ACR350 Parts Description

10 11
9
12 13
14
15
