3.2.3.
Barcode Module
The Barcode module can show the validity of the test cards thru QR code on Page 1 and display the
details of any barcode or QR code on Page 2.
3.2.3.1.
Barcode / QR code Validity Check
Page 1 shows the validity of the barcode on the test cards.
Note: test cards are included in the ACR350 EVK.
1. Select "Barcode".
Note: The same QR code will not be accepted within 3 seconds to avoid duplicated transactions.
ACR350 Validator with QR Code Scanner – User Manual
Version 1.02
2. The ACR350 will wait for
the card to be presented.
4. a. If the QR code is valid, a
"SUCCESS" message will
be displayed.
Figure 27: Barcode / QR code Validity Check
3. Scan the card with the QR
code facing the sensor.
4. b. Otherwise, an "ERROR"
message will be displayed.
info@acs.com.hk
www.acs.com.hk
Page 49 of 61
