6. Select the appropriate hole cover according to the orientation of the pole, as shown in the
photo and in the table below:
Orientation of pole
for mounting
Horizontal
Vertical
ACR350 Validator with QR Code Scanner – User Manual
Version 1.02
HT
VT
31/32mm
VT, VT
HT, HT
Table 6: Hole Cover According to Pole Size and Orientation
HT
VT
Pole diameter
35mm
VT, VT
HT, HT
HT for Vertical Pole
VT for
Horizontal Pole
Page 16 of 61
