Note: The gap between the two metal parts is around 3mm for any size (31/32/35mm) of
pole.), as shown in the picture below.
3. Screw the rubber adapters and hole covers using PB2.0 (2 pieces). The exact position is
shown in the photos below:
ACR350 Validator with QR Code Scanner – User Manual
Version 1.02
VT
Note: This is where the Connection
Cable (ie, Power Cord) will go
through. Make sure that the cables
are out so that they may be easily
connected to the ACR350 Validator
later on.
VT
info@acs.com.hk
www.acs.com.hk
Page 25 of 61
