4. Using the codes on their inner side, select the rubber adaptors that match the pole's size
and orientation, as shown in the table below:
Orientation of pole
for mounting
Horizontal (H)
Vertical (V)
5. Open the brown box. The following components should be inside the box:
Rubber Part
ACR350 Validator with QR Code Scanner – User Manual
Version 1.02
For 35mm Pole
31/32mm
HB-D31/32, HB-D31/32,
HT-D31/32, HT-D31/32,
VB-D31/32, VB-D31/32,
VT-D31/32, VT-D31/32,

Table 5: Rubber Adapter According to Pole Size and Orientation

Screws
For 31/32mm Pole
Pole diameter
HB-D35, HB-D35,
HT-D35, HT-D35,
VB-D35, VB-D35,
VT-D35, VT-D35,
Brown Box
Metal Part 1
35mm
Metal Part 2
Hole Cover
Page 15 of 61
