„ Standard accessories
Number differs by package
No. Part name
(1) Loop harness (cable between
OC-907C T and OA-607 T)
(2) Pass-through harness between
OA-607 T and OA-607 T
(3) For door
Door loop cover
loop
(4)
Jamb cover
(5)
Corrugated tube
(6) I/O harness
Signal line between OC-907C T
and door controller, 12-pole cable
(7) Power harness
Power line between OC-907C T
and door controller, 2-pole cable
-
Mounting
For OA-607 T
screws
-
For door loop cover
or Jamb cover
-
Mounting
For OA-607 T
templates
-
For Jamb cover
-
T-tap connector (male/female)
-
Hook-and-loop fastener
Appearance
Smaller connector
Larger connector
(connected to
(connected to
OC-907C T)
OA-607 T side via door
loop cover)
2'4'' type
1' type
Silver
Black
Description
For connecting the sensor controller and
OA-607 T (via door loop cover), length 7'3"
(2200 mm)
For connection between door front/back
(inner/outer) OA-607 T, length 210 mm
Door loop cover through which the loop
harness passes. The loop harness is con-
nected from there on the side of OA-607 T.
Installed on the jamb side, this cover
conceals the loop harness takeout hole
from the jamb side while the harness is run
through.
The loop harness runs through this tube
between the jamb cover and the door loop
cover.
The following two lengths are included.
• 2'4" type: For door loop with concealed
wiring
• 1' type: For door loop with exposed wiring
• The longer 2'4" type is intended for stan-
dard concealed wiring applications.
• The shorter 1' type is intended for ex-
posed wiring applications (wiring exposed
rather than embedded from the jamb
cover within the jamb).
Signal line for connection between door
controller and OC-907C T, length 4'3"
(1300 mm)
Power line for connection between door
controller and OC-907C T, length 3'
(920 mm)
NOTE
NOTE
No polarity.
Mounting screws for OA-607 T
Color: Silver
Mounting screws for door loop cover and
jamb cover
Color: Black
Templates for OA-607 T mounting holes,
door leaf front/back through holes, and
door loop cover
Set of door leaf (R) and (L)
Template for jamb cover
A voltage line branch connector for confirm-
ing whether there is output voltage from the
door controller to the connected motor
Double-sided tape for mounting OC-907C T 1
Number per package
ELITE
ELITE
ELITE
PRO
PRO
PRO2
LE
1
2
2
0
1
2
1
2
2
1
2
2
1
1
1
2
4
8
4
8
8
1
2
2
1
2
2
2
4
4
1
1
3
