A8117G(M1)
12/20
Copyright © 2020, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
SN
Series
SN200 Wiegand
SN210 OSDP
Cylindrical Lock
Installation Instructions
Advertisement
Related Manuals for Sargent ASSA ABLOY SN Series
Summary of Contents for Sargent ASSA ABLOY SN Series
- Page 1 SN200 Wiegand SN210 OSDP Cylindrical Lock Installation Instructions A8117G(M1) 12/20 Copyright © 2020, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 2: Table Of Contents
SN200/210 Cylindrical Lock Table of Contents Regulatory Compliance ............3 Warning ................. 3 General Description .............. 5 Specifications/Features ............5 Parts Breakdown ..............7 Wiring Diagrams ..............9 Installation Instructions ............. 12 Operational Check .............. 20 A8282A • 800-810-WIRE (9473) • www.sargentlock.com... -
Page 3: Regulatory Compliance
Pour plus d’informations, visitez: www.P65warnings.ca.gov. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 4: General Description
SN200/210 Cylindrical Lock General Description The SARGENT SN200/210 Series brings the latest in security and versatility to our Integrated Wired access control solutions. Featuring Signo Reader Technology from HID Global , the SN200/210 Series ® is ideal for mixed credential environments and enables easy migration to higher security credentials and mobile access. - Page 5 SN200/210 Cylindrical Lock Specifications / Features (Continued) • UL Listed* - UL 294 Indoor Use • UL 294 Access Control Ratings: • CUL Listed - S319: Class 1 Destructive Attack Level 1 • ANSI/BHMA A156.25 Listed Line Security Level 1 Grade 1 Compliant Endurance Level 4...
-
Page 6: Parts Breakdown
SN200/210 Cylindrical Lock Parts Breakdown Tools Required: • #2 Phillips screwdriver • Push pin (provided) • T10 Torx Driver • 3/32” drill bit • 3/4” drill bit • 5/16” drill bit • 3/8” drill bit • 7/16” drill bit • 1”... - Page 7 SN200/210 Cylindrical Lock Parts Breakdown (Continued) 11 * Adapter Plate/Spacer (10-0847) is only shipped with orders that specify 1-3/8” doors. ITEM PART # DESCRIPTION REQ. Refer to SN200/210 Catalog for Available Lever Styles Refer to SN200/210 Catalog for Available Cylinders 10-3049 Outside Rose Spring Assembly 10-0850...
- Page 8 SN200/210 Cylindrical Lock Parts Breakdown (Continued) ITEM PART # DESCRIPTION (STD, 10, 10-21, 11, 11-21, 21, 22, SC, SE, VA, VS) CYL Lockbodies 10-3360 10G270-24V Fail Safe Lock body Assembly 10-3364 10G271-24V Fail Secure Lock body Assembly 10-3361 10G270-12V Fail Safe Lock body Assembly 10-3365 10G271-12V Fail Secure Lock body Assembly (60, 63, 64) CYL Lockbodies...
-
Page 9: Wiring Diagrams
SN200/210 Cylindrical Lock Wiring Diagrams Product 8 PIN CONNECTOR 4 PIN CONNECTOR 1-Black 2-Red 3-White 4-Green 5-Orange 6-Blue 7-Brown 8-Yellow 1-Violet 2-Gray 3-Pink 4-Tan ACCESS CONTROL DEVICES: SN200/210 Mortise, ElectroLynx wire Color / Function assignments SN200 12VDC WIEGAND WIEGAND EGND 12/24 VDC GREEN_LED (Reader) - Page 10 SN200/210 Cylindrical Lock Wiring Diagrams (Continued) Wiegand SN200 Lock Application Diagram #1 Connect GREEN_LED input to switch controlled by panel. Shorting GREEN_LED to READER_NEG (Black) with panel switch will override reader LED to keep it green. 12/24VDC System Average Peak Average Peak Reader*...
- Page 11 SN200/210 Cylindrical Lock Wiring Diagrams (Continued) OSDP SN210 Diagram #2 (12/24VDC System) Average Peak Average Peak Reader* 75mA 250mA Actuator 500mA 500mA 250mA 250mA Reader Electronics Requires 12VDC Filtered and Regulated Tamper will trigger when reader is removed from door and tamper monitoring is enabled at the panel** Power Supply 120 VAC...
-
Page 12: Installation Instructions
SN200/210 Cylindrical Lock Installation Instructions 1 Door Preparation A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Left Hand Left Hand Right Hand Right Hand Hinges Left. Reverse Bevel Hinges Right. Reverse Bevel Open Inward. - Page 13 Use SARGENT 3287 Concealed Door Position Switch with this Access Control System SN200/210 10-Line Product: 1. Install the 3287 Concealed Door Position Switch described in SARGENT document A7448B. 2. Wire the 3287 Concealed Door Position Switch to the ElectroLynx frame harness to the door position switch wires.
- Page 14 SN200/210 Cylindrical Lock 5 Install Reader Backplate and (Optional*) Fire Shield 1. For fire-rated doors only, install reader backplate and fire shield to door using two (2) #8-18 x 5/8” Phillips flat head self-drilling screws (Fig. 5). 2. For exterior doors, install reader backplate using two (2) #8-18 x 5/8” Phillips flat head self-drilling screws (Fig.
- Page 15 SN200/210 Cylindrical Lock 6 Installation of SN200/210 Reader Observe precautions for handling electrostatic sensitive devices. 1. Feed reader harness through door (Fig. 6A). 2. Hook the top of the reader on the top of the mounting plate (Fig. 6B). 3. Align the bottom of the reader with the bottom of the mounting plate. 4.
- Page 16 SN200/210 Cylindrical Lock 7 How to Remove Outside Lever (If Necessary) 1. Insert key, rotate 45° clockwise and hold Outside of Door (Fig. 7A, B). 2. Depress lever retainer with push pin tool (provided). 3. Reverse this procedure to reassemble. Note: Be sure spacer is installed on the back of cylinder plug.
- Page 17 SN200/210 Cylindrical Lock 9 Install Lock Body (Continued) C. Install Lock: 1. Feed wires into the lock body hole, from outside of door (Fig. 9B). 2. With outside lever horizontal, insert the mounting post through outside of door and lock body. Inside of Door (Wood) NOTE: Make certain the lever spindle is properly...
- Page 18 SN200/210 Cylindrical Lock 11 Wire Connections Do not offset connectors and ensure that they are completely seated. 1. Connect 6-pin connector from lock body to 6-pin connector on reader harness (Fig. 11A). 2. Connect 2-pin connector from lock body to 2-pin connector on reader harness (Fig. 11A). Fig.
- Page 19 SN200/210 Cylindrical Lock 12 Fire Plate Installation and Earth Ground Connection 1. Remove lower left screw from mounting plate. Feed screw through green/yellow ground wire ring terminal. Reinstall screw. Ensure that green/yellow wire points toward top of door in order to avoid interference with escutcheon. 2.
-
Page 20: Operational Check
SN200/210 Cylindrical Lock Operational Check 1. Insert key into cylinder and rotate: The key will retract the latch. The key should rotate freely. 2. Ensure inside lever retracts latch. 3. Close door: Ensure latch is fully extended and does not bind. Note: Once electrical wiring has been successfully completed according to proper application, perform the following:... - Page 21 SN200/210 Cylindrical Lock Operational Check (Continued) Note: Once electrical wiring has been successfully completed according to proper application, perform the following steps: 1. Ensure lock is interfaced with Wiegand Test Unit to verify installation & wiring up to (frame side) point of hinge. 2.
- Page 22 SN200/210 Cylindrical Lock Notes A8282A • 800-810-WIRE (9473) • www.sargentlock.com...
- Page 24 © Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. HID, the HID logo, iCLASS SE, iCLASS, and Edge are trademarks or registered trademarks of HID Global in the U.S. and/or other countries.
