Summary of Contents for Sargent ASSA ABLOY Harmony Series
- Page 1 Harmony Series Cylindrical Lock Installation Instructions A7884E 06/17 Copyright © 2017, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 2: Table Of Contents
Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated open- ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 3: General Description
Harmony Series H1 Cylindrical Lock General Description The SARGENT Harmony Series H1 Cylindrical Lock is designed to interface with existing Wiegand Electronic Access Control (EAC) panels. The reader requires 12VDC for power and is available with 125 kHz HID proximity technology. The H1 technology is backed by SARGENT’s Grade 1 hardware. -
Page 4: Wiring Diagrams
1-Black 2-Red 3-White 4-Green 5-Orange 6-Blue 7-Brown 8-Yellow 1-Violet 2-Gray 3-Pink 4-Tan ACCESS CONTROL DEVICES: Harmony H1, ElectroLynx wire Color / Function assignments SARGENT - 12/24VDC WIE- WIE- EGND 12/24 VDC GAND GAND (NC) (COM) HARMONY (Reader) (LOCK RELAY) SERIES... - Page 5 Harmony Series H1 Cylindrical Lock Typical Harmony Cylindrical Application Diagram (12/24VDC Lock) MODE 1: RED LED ‘ON’ WHEN POWERED Standard Application Shown - For Alternative Applications Contact 1-800-810-WIRE (9473) Reader Electronics Require 12 or 24VDC UL294 Listed, Power Limited Power Supply (or UL603) 12VDC System 24VDC System •...
-
Page 6: Parts Breakdown
Harmony Series H1 Cylindrical Lock Parts Breakdown Lever Hand Reverse Door Prior to installation, please confirm receipt of all parts. *Adapter Plate is only shipped with orders that specify 1-3/8” doors. *If you are replacing iCLASS-only product: • Replace both reader & controller with SE products Tools Required: Consult factory for details •... - Page 7 Harmony Series H1 Cylindrical Lock Parts Breakdown (Continued) Lever Hand Reverse Door ITEM PART # Description Req. ITEM PART # Description Req. 52-5187 Outside Escutcheon Assembly (82) CYL Lock bodies 52-0792 Outside Weather Gasket 10-3384 10G 270-24V Fail Safe Lock body Assembly 52-0791 Inside Weather Gasket 10-3388...
-
Page 8: Installation Instructions
Harmony Series H1 Cylindrical Lock Installation Instructions 1 Door Preparation A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Left Hand Left Hand Right Hand Right Hand Hinges Left. Reverse Bevel Hinges Right. Reverse Bevel Open Inward. - Page 9 System integrator will determine the use and installation location. Control System 2. If SARGENT 3287 Concealed DPS installation is specified, use SARGENT template A7448 to prepare the door and frame at desired location. 3. Wire the 3287 Concealed DPS to the ElectroLynx frame harness to the door position switch wires.
- Page 10 Harmony Series H1 Cylindrical Lock 5 Lock Installation A. Lock Preset Outside of • Lock body holes – 12 and 6 o’clock (Fig. 5A) Door • Door thickness – 1-3/4” thick (refer to B for minor adjustments) Through-bolt Holes B. Through-bolt Minor Adjustments Spacer Bushing •...
- Page 11 Harmony Series H1 Cylindrical Lock 6 Secure Lock to Door 1. Feed wire and connector: • For wood door, feed connectors and wires through the door and up the wire run channel (Fig. 6A). • For metal door (not shown), feed connectors and wires into the lockbody hole and out the controller hole. 2.
- Page 12 Harmony Series H1 Cylindrical Lock 7 Lever and Cylinder Removal (If Necessary) Standard Cylinder 1. Insert key, rotate 45° clockwise and hold (Fig. 7A). 2. Depress lever retainer with push pin tool (provided). 3. Reverse this procedure to reassemble. Fig. 7A Note: Be sure spacer is installed on the back of cylinder plug.
- Page 13 Harmony Series H1 Cylindrical Lock Outside of Door 9 Installation of Outside Escutcheon, Lever and Gaskets Escutcheon Screws #8-32 X 2” Long Outside of Door Phillips Flat Head Screw 1. Feed the reader cable connector located on the back of the outside es- Gasket Outside for Harmony cutcheon from the outside of the door...
- Page 14 Harmony Series H1 Cylindrical Lock 11 Wire Positioning Please follow these steps prior to installing inside escutcheon assembly to prevent any damage caused by pinching wires: 1. Insert the ElectroLynx connectors (8- and 4-pin) and establish their position inside the door prep (Fig. 11A). 2.
-
Page 15: Operational Check
Harmony Series H1 Cylindrical Lock Operational Check For devices with cylinders: 1. Insert key into cylinder and rotate: The key will retract the latch. The key should rotate freely. 2. Ensure inside lever retracts latch. 3. Close door: Ensure latch is fully extended and does not bind. - Page 16 New Haven, CT 06511 USA 800-727-5477 • www.sargentlock.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices,electro-mechan- ical products and access control systems for new construction, renovation, and replacement applications.The company’s customer base includes commercial construction, institutional, and industrial markets.
