- Page 1 Certification Exhibit FCC ID: U4A-SCYICLS2 IC: 6982A-SCYICLS2 FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 11-0071.W06.11.A Manufacturer: Assa Abloy, Inc. Model: P2-IM/IKM Manual 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598...
- Page 2 PASSPORT 1000 Mortise Lock Installation Instructions A8011E 12/10 Copyright 2010, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 3: Table Of Contents
Table of Contents Warning ...................2 General Description ..............3 Hardware Specifications ............3 Electronic Specifications ............3 Parts Breakdown ..............4 Installation Instructions ............7 Operational Check ..............14 Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: General Description
Passport 1000 Series P2 Mortise Lock General Description The SARGENT Passport Series v.P2 Mortise Lock is available with either an HID® Prox 125 kHz or 13.56 MHz iCLASS® Designed specifically for the campus market, the SARGENT Passport 1000 P2 WiFi Mortise technology reader. -
Page 5: Parts Breakdown
Passport 1000 Series P2 Mortise Lock Parts Breakdown P2 WiFi Lock with Magnetic Card Swipe With or Without Keypad Inside Inside Inside Outside Outside Outside ITEM No. PART No. DESCRIPTION 52-0757 Lens (Cliplite) 52-0738 Outside Passport Escutcheon Only (Magnetic Swipe and Keypad) 52-0739 Outside Passport Escutcheon Only (Magnetic Swipe) 52-0760... - Page 6 Passport 1000 Series P2 Mortise Lock Parts Breakdown (Continued) P2 WiFi Lock with Magnetic Card Swipe, 125 kHz and Keypad Inside Inside Outside Outside ITEM No. PART No. DESCRIPTION 52-1103 Outside Passport Escutcheon only (Magnetic Swipe, Keypad and Proximity Reader) 52-3593 Slim Style Keypad Assembly 01-9299...
- Page 7 Passport 1000 Series P2 Mortise Lock Parts Breakdown (Continued) P2 WiFi Lock with Magnetic Card Swipe, 13.56 MHz and Keypad ITEM No. PART No. DESCRIPTION 52-4402 Outside Mask Assembly 52-1255 Outside Escutcheon - iCLASS 52-3593 Slim Style Keypad Assembly 01-9299 #4-40 x 3/16”...
- Page 8 Passport 1000 Series P2 Mortise Lock Parts Breakdown (Continued) 8200 Series Mortise Lock ITEM PART No. DESCRIPTION See catalog #41 Cylinder (1-1/8” Minimum Length) 13-0140 Cylinder Compression Spring See catalog 1KB-1 Cylinder Rosette See catalog Mortise Lockbody 77-2592 130 KB Thumbturn for Deadbolt Functions Only See catalog Inside Lever Handle See catalog...
-
Page 9: Installation Instructions
Passport 1000 Series P2 Mortise Lock Installation Instructions Door Preparation A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Left Hand Left Hand Right Hand Right Hand Hinges Left. Reverse Bevel Hinges Right. Reverse Bevel Open Inward. - Page 10 Passport 1000 Series P2 Mortise Lock Connector 2 How to Change Hand of Lockbody Ring Terminal A. Reverse Lock Hand Red surface of locking piece must face the outside/ locked side of door. To rotate locking piece (Fig. 2A): 1. Position lock body with red surface of locking piece visible.
- Page 11 Cylinder should be flush with rosette/collar. Note: SARGENT logo must be horizontal and on the top of the cylinder (Fig. 4B). 2. Secure the cylinder by tightening cylinder clamp screw located above the deadbolt.
- Page 12 Passport 1000 Series P2 Mortise Lock 5 Install Inside and Outside Levers 1. Slide the outside lever and spindle assembly through the door and lockbody. 2. Using the inside adapter plate and spindle, secure loosely with (2) #8-32 screws. Note: Position threaded hole on the inside adapter to align with lever hole. 3.
- Page 13 Passport 1000 Series P2 Mortise Lock 7 Install Gasket (Optinal) Note: Optional, for non-fire rated doors only. For non-fire rated door applications, an optional gasket may be used as a weather seal between the escutcheon and the outside Gasket door surface. Peel off adhesive backing and attach to outside escutcheon.
- Page 14 Passport 1000 Series P2 Mortise Lock 9 Install Inside Module Component Assembly Insert bottom of Module Component Assembly first (Fig. 9A), then clip top of Assembly to backplate, verifying both tabs attached securely. Tabs Outside of Door Fig. 9A 10 Attach Connectors Secure the following connectors onto the circuit board (Fig.
-
Page 15: Operational Check
Passport 1000 Series P2 Mortise Lock 11 Install Battery/Battery Pack 1. Place (6) “AA” batteries into the compartment be- ing careful to align polarity (- & +) properly. 2. Insert battery pack and click into place, making sure polarity terminals on the battery pack are correctly oriented (Fig. - Page 16 Passport 1000 Series P2 Mortise Lock 13 Attach Outside Front Plate Attach front plate with (2) #8-32 X 1/4” flat head screws (Fig. 13A). (2) #8-32 x 1/4” Flat Head Screws Fig. 13A 1-800-810-WIRE • www.sargentlock.com • A8011E...
- Page 17 New Haven, CT 06511 USA 800-810-WIRE (9473) • www.sargentlock.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications. The company’s customer base includes commercial construction, institutional, and industrial markets.
