Sargent ASSA ABLOY IN100 Series Installation Instructions Manual

Mortise lockset with aperio technology
Hide thumbs Also See for ASSA ABLOY IN100 Series:
Table of Contents

Advertisement

Quick Links

Installation Instructions
IN100 Series
with Aperio
Technology
7900 / 8200
Mortise Lockset
Attention Installer:
Please read these instructions carefully to prevent
missing important steps.
Improper installations may result in damage to the
lock and void the factory warranty.
The accuracy of the door preparation is critical for
proper functioning and security of this lock.
Misalignment can cause premature wear and a
lessening of security.
A8190E
02/21
Copyright 2016, 2020-2021, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASSA ABLOY IN100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sargent ASSA ABLOY IN100 Series

Summary of Contents for Sargent ASSA ABLOY IN100 Series

  • Page 1 Misalignment can cause premature wear and a lessening of security. A8190E 02/21 Copyright 2016, 2020-2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    IN100 Series Mortise Lock Installation Instructions Table of Contents Warning ..................3 General Description ................4 Hardware Specifications ..............4 Electronic Specifications ..............4 Parts Breakdown ................5 Lock Installation ................8 Operational Check ................18 Communication Hub LED Indications ............ 19 Lock LED Indications ...............

  • Page 3: Warning

    équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

  • Page 4: General Description

    ® ® credentials, including mobile access. All technology features are supported by the physical security of SARGENT ANSI/BHMA Grade 1 hardware - quality components that provide high security, performance and durability. Hardware Specifications •...

  • Page 5: Parts Breakdown

    IN100 Series Mortise Lock Installation Instructions Parts Breakdown Tools Required: • #2 Phillips screwdriver • Flat blade screwdriver • 1/8" Security Allen Wrench ITEM No. DESCRIPTION Aperio Reader Assembly Mounting Plate Assembly (includes gasket) Aperio Controller AA alkaline batteries (6) Branded Battery Cover Assembly with Privacy Button 1-800-810-WIRE •...
  • Page 6 IN100 Series Mortise Lock Installation Instructions Parts Breakdown continued Door Position Switch (DPS) #41 Mortise cylinder Cylinder Rosette (Thumb)Turn Lock front Lever 7900 Lock body only Trim Pack Outside Trim Inside Inside Lock body (7900) Lever Rose ITEM Part Number/Order String Description Consult Factory #41 Mortise cylinder...
  • Page 7 IN100 Series Mortise Lock Installation Instructions Lock Installation 1 Prepare door a. Verify hand and bevel of door. (Figure 1) NOTE: Stand on outside of locked door when determining door hand. b. Prepare door according to appropriate template. (Figure 2) See website www.intelligentopenings.com.

  • Page 8: Lock Installation

    IN100 Series Mortise Lock Installation Instructions Lock Installation 2A Prepare 7900 Lock Body* *If 7900 is type of lock being installed 1. Reverse Lock Hand (If Required) Red surface of locking piece must face the out- side/locked side of door. To rotate locking piece (Fig.
  • Page 9 IN100 Series Mortise Lock Installation Instructions Lock Installation continued 4. Install **Door Position Switch (DPS) a. Push wire harness through raceway toward lock prep. Inside of b. Push DPS firmly into place by hand. Door Note: DO NOT TAP SWITCH WITH ANY TOOL. c.
  • Page 10 IN100 Series Mortise Lock Installation Instructions Lock Installation continued 3A Prepare 8200 Lock Body* *If 8200 is type of lock being installed 1. Reverse Lock Hand (If Required) Right Hand Red surface of locking piece must face the out- Lock Shown side/locked side of door.
  • Page 11 IN100 Series Mortise Lock Installation Instructions Lock Installation continued 3B Install 8200 Lock Body Note: Do not pull the lock into the pocket using the harness alone. Ensure that the wire harness is not pinched between the lock and the mortise pocket. 1.
  • Page 12 • Key retracts latchbolt (7978 & 82278 function). Spring • Cylinder not present for 7977, 7979, 82277 or 82279 functions. Cylinder IMPORTANT: Position cylinder so that SARGENT logo is positioned correctly. Correct Incorrect Fig. 4A *Same for 7900 and 8200 (7900 shown) Fig.
  • Page 13 IN100 Series Mortise Lock Installation Instructions Lock Installation continued Assemble outside trim a. With outside lever horizontal (handle Outside pointing toward door hinge), insert of Door mounting posts through outside of door and lockbody. (Figure 5A) NOTE: Make certain lever spindle is properly engaged inside lockbody.
  • Page 14 IN100 Series Mortise Lock Installation Instructions Lock Installation continued 6 Install inside rose and inside lever assembly* Inside a. Place inside rose flush against door surface of Door and rotate first counter-clockwise to seat threads, then clockwise to securely tighten. b.
  • Page 15 IN100 Series Mortise Lock Installation Instructions Lock Installation continued 9 Install outside reader a. Orient reader so LED lens is at top. (Figure 9A) b. Feed cable/connector through door from outside to inside. NOTE: Cable lengths exaggerated for illustrative purposes. c.
  • Page 16 IN100 Series Mortise Lock Installation Instructions Lock Installation continued h. Secure the following connectors to their *Optional 12-24VDC Power respective terminals (Figure 9A, C): Remote Power Harness Wire Terminations CAUTION: Do not touch or allow debris to enter 2-pin Black PS (-) Return connector contacts.
  • Page 17 IN100 Series Mortise Lock Installation Instructions Lock Installation continued Install inside component assembly (controller) a. Insert bottom tab of controller - (ensure path is clear) into slot on mounting plate. (Figure 10A) b. Ensure proper alignment of board-to-board connectors while pivoting controller toward door until two tabs on top click securely into place on mounting plate.

  • Page 18: Operational Check

    IN100 Series Mortise Lock Installation Instructions Lock Installation continued Install inside cover (Figure 22) a. Assemble cover by hooking top edge on inside mounting plate. b. Carefully press bottom of cover toward door without pinching or damaging wires. Inside c. Secure cover utilizing security allen Cover wrench (provided).

  • Page 19: Communication Hub Led Indications

    IN100 Series Mortise Lock Installation Instructions Communication Hub LED Indications Communication hub has a single LED. It supports an optical scheme of red, green and yellow. Indication scheme is described by figures below: Communication Hub NORMAL OPERATION LED indication 2 sec. Online Green Aperio...

  • Page 20: Lock Led Indications

    IN100 Series Mortise Lock Installation Instructions Lock LED Indications Lock has three (3) LEDs. They support an optical scheme with red, yellow and green. Indication scheme described by figures below: Lock NORMAL OPERATION LED indication EAC response Enter PIN time One yellow flash after card, two flashes Card + PIN access (configurable) before PIN (.125 second)

  • Page 21: Lock Self-Test Led Indications

    IN100 Series Mortise Lock Installation Instructions Lock Self-Test LED Indications After replacing batteries, a Power on Self Test (POST) is performed. The result is indicated using a series of red and green LED flashes as described by figures below: Battery Not Fully Charged Error in lock is an indication -10 quick (125ms) red blinks, that either new batteries are not at right voltage or a backward battery has been installed;...

  • Page 22: Lock Busy Led Indications

    IN100 Series Mortise Lock Installation Instructions Lock Busy LED Indications Lock BUSY indicates lock is processing a card (such as a key configuration card for online SE processor or offline void list card with many entries). Card should be kept in close proximity to reader until end of process. Lock BUSY indication does not cancel or overwrite any other indications.
  • Page 23 IN100 Series Mortise Lock Installation Instructions 1-800-810-WIRE • www.sargentlock.com • A8190E...
  • Page 24 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2016, 2020-2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. A8190E - 02/21 Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
