- Page 1 Aperio ™ Technology Cylindrical Lock (M1) A8189D 11/19 Copyright © 2019, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 2: Table Of Contents
IN100 Series Cylindrical Lock Installation Instructions Table of Contents Warning ..................3 General Description ................4 Hardware Specifications ..............4 Electronic Specifications ..............4 Parts Breakdown ................5 Lock Installation ................7 Operational Check ................16 Communication Hub LED Indications ............ 17 Lock LED Indications ............... -
Page 3: Warning
équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 4: General Description
Installation Instructions General Description The SARGENT ® IN100 lock with Aperio™ Technology makes it easy and cost-effective to bring access control to more doors. It uses local wireless communication between the lock and an Aperio hub to connect to an access control system, eliminating the greatest cost and inconvenience of traditional access control –... -
Page 5: Parts Breakdown
IN100 Series Cylindrical Lock Installation Instructions Parts Breakdown Tools Required: • #2 Phillips screwdriver • 1/8" Security Allen Wrench ITEM PART NUMBER/ORDER STRING DESCRIPTION COLOR/TRIM IN-100-EM0110G77-IP-B HID iCLASS , HID iCLASS SE (SIO-enabled), HID iCLASS Seos™, HID MIFARE Black ® ®... - Page 6 IN100 Series Cylindrical Lock Installation Instructions Parts Breakdown continued ITEM Part Number/Order String Description Outside Lever (Reference Catalog for Available Styles) 10-0043 Lever Retainer Key (In Screw Pack 10-2052) Cylinder Assembly (Reference Catalog for Available Cylinders) Rose (Reference Catalog for Available Styles) 10-0792 Spacer Bushing 10-3049...
-
Page 7: Lock Installation
IN100 Series Cylindrical Lock Installation Instructions Lock Installation Prepare door. a. Verify hand and bevel of door. (Fig. 1) NOTE: Stand on outside of locked door when determining door hand. b. Prepare door according to appropriate template. (Fig. 2) See website www.intelligentopenings.com LHRB •... - Page 8 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued Centerline of Install strike in door frame. (Fig. 3) Latch Front and Strike Install latchbolt. (Fig. 4) a. Install latch with beveled bolt facing strike. (Fig. 5) (2) #8-32 x 3/4" Latch Screws b.
- Page 9 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued Adjust lock. a. Lockbody holes are at 12 and 6 o’clock. (Fig. 7) Outside of Door NOTE: • Lock is shipped “preset” and does not require adjustment for 1-3/4" thick doors •...
- Page 10 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued c. Adjust through-bolt and door thickness if necessary. • Remove outside lever, scalp and spacer bushing (Fig. 10) • Rotate mounting plate to either align with through-bolt holes in door, or adjust for proper door thickness.
- Page 11 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued Install lock. a. From outside of door feed lockbody harness into lockbody hole. (Fig. 13) Outside For metal door: Feed harness through inside of of Door door (not shown). b. Continue to feed harness into raceway (towards top of door), exiting raceway hole on inside of door.
- Page 12 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued Secure lock to door. a. Slide inside rose assembly and spacer bushing over lockbody. Inside of Door b. Position ground lug between (top) #10-32 x 1-1/4" through-bolt and rose assembly. (Fig. 16) NOTE: Proper placement of ground wire will prevent pinching/damage to ground wire.
- Page 13 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued 10. Install outside reader. NOTE: Cable lengths exaggerated for illustrative purposes. a. Orient reader so LED lens is at top. (Fig. 19) b. Feed cable/connector through door from Outside outside to inside. of Door c.
- Page 14 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued h. Secure the following connectors to their *Optional 12-24VDC Power respective terminals (Fig. 22): Remote Power Harness Wire Terminations CAUTION: Do not touch or allow debris to 2-pin Black PS (-) Return enter connector contacts.
- Page 15 IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued Install inside component assembly (controller). a. Insert bottom tab of controller (make sure path is clear) into slot on mounting plate. (Fig. 25) Controller b. Ensure proper alignment of board-to-board connectors while pivoting controller toward door until two tabs on top click securely into place on mounting plate.
-
Page 16: Operational Check
IN100 Series Cylindrical Lock Installation Instructions Lock Installation continued Install inside cover. (Fig. 28) a. Assemble cover by hooking top edge on inside mounting plate. b. Carefully press bottom of cover toward door without pinching or damaging wires. c. Secure cover utilizing security allen Inside wrench (provided). -
Page 17: Communication Hub Led Indications
IN100 Series Cylindrical Lock Installation Instructions Communication Hub LED Indications Communication hub has a single LED. It supports an optical scheme of red, green and yellow. Indication scheme is described by figures below: Communication Hub NORMAL OPERATION LED indication 2 sec. Online Green Aperio... -
Page 18: Lock Led Indications
IN100 Series Cylindrical Lock Installation Instructions Lock LED Indications Lock has three (3) LEDs. They support an optical scheme with red, yellow and green. Indication scheme described by figures below: Lock NORMAL OPERATION LED indication EAC response time Enter PIN One yellow flash after card, two flashes Card + PIN access (configurable) before PIN (.125 second) -
Page 19: Lock Self-Test Led Indications
IN100 Series Cylindrical Lock Installation Instructions Lock Self-Test LED Indications After replacing batteries, a Power on Self Test (POST) is performed. The result is indicated using a series of red and green LED flashes as described by figures below: Battery Not Fully Charged Error in lock is an indication -10 quick (125ms) red blinks, that either new batteries are not at right voltage or a backward battery has been installed;... -
Page 20: Lock Busy Led Indications
IN100 Series Cylindrical Lock Installation Instructions Lock Busy LED Indications Lock BUSY indicates lock is processing a card (such as a key configuration card for online SE processor or offline void list card with many entries). Card should be kept in close proximity to reader until end of process. Lock BUSY indication does not cancel or overwrite any other indications. - Page 21 IN100 Series Cylindrical Lock Installation Instructions A8189D • 800-810-WIRE (9473) • www.sargentlock.com...
- Page 22 IN100 Series Cylindrical Lock Installation Instructions A8189D • 800-810-WIRE (9473) • www.sargentlock.com...
- Page 23 IN100 Series Cylindrical Lock Installation Instructions A8189D • 800-810-WIRE (9473) • www.sargentlock.com...
- Page 24 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2019, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. A8189D - 11/19 Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
