Sargent IN220 Installation Instructions Manual

Mortise lock
Hide thumbs Also See for IN220:

Advertisement

Quick Links

A8204B
04/16
Copyright 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
IN220
PoE
Mortise Lock
Installation Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the IN220 and is the answer not in the manual?

Questions and answers

Related Manuals for Sargent IN220

Summary of Contents for Sargent IN220

  • Page 1 IN220 Mortise Lock Installation Instructions A8204B 04/16 Copyright 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 3: Table Of Contents

    équivalente (p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

  • Page 4: General Description

    IN220 Mortise Lock General Description The SARGENT IN220 Mortise lock combines superior aesthetics with the energy efficiency and streamlined architecture of Power-over-Ethernet (PoE) access control. PoE-enabled access control allows facilities to leverage existing network infrastructure for enhanced security and easier, more cost-effective installations.

  • Page 5: Parts Breakdown

    IN220 Mortise Lock Parts Breakdown PART NO./ORDER ITEM QTY. DESCRIPTION STRING IN-220-EM01-[B*]IP-B Reader assembly - black plastic IN-220-EM01-[B*]IP-W Reader assembly - white plastic IN-220-EM01-[B*]IP-MB-xxx** Reader assembly - black plastic with metal trim IN-220-EM01-[B*]IP-MW-xxx** Reader assembly - white plastic with metal trim...
  • Page 6 IN220 Mortise Lock Parts Breakdown (Continued) PART NO/ORDER ITEM STRING DESCRIPTION Consult Factory #41 Mortise cylinder Consult Factory Cylinder Rosette IN-220-7976-hand-fin Lock body with deadbolt with cylinder IN-220-7977-hand-fin Lock body with deadbolt without cylinder IN-220-7978-hand-fin Lock body without deadbolt with cylinder...

  • Page 7: Installation Wiring

    IN220 Mortise Lock Installation Wiring Overview SARGENT IN220 PoE Typical Application Network Cable Surface Mount RJ45 Network Switch (802.3af) LMT: Lock Management Tool A. PoE frame harness assembly B. PoE data hinge from McKinney C. PoE door harness* from McKinney D.
  • Page 8 IN220 Mortise Lock Installation Wiring (Continued) Supplied by CI Certified Integrator (CI) supplies and terminates Supplied by End User the B-Splice connector and the PoE Switch male RJ45 connector from harness to end user provided facility cable B-Splice Patch Cable...
  • Page 9 IN220 Mortise Lock Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney. Suggested installation: Supplied by CI Cut end / ceiling-side PoE harness: B-Splice Crimp Connector TIA/EIA 568-B Standard Wiring Wire Pair Number White/Orange Orange RJ45-M...
  • Page 10 IN220 Mortise Lock PoE Door Harness Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: • Ring terminal •...

  • Page 11: Lock Installation

    IN220 Mortise Lock Lock Installation 1 Prepare Door A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Fig. 1A LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel...
  • Page 12 IN220 Mortise Lock 2A Prepare 7900 Lock Body* *If 7900 is type of lock being installed 1. Reverse Lock Hand (If Required) Red surface of locking piece must face the outside/locked side of door. To rotate locking piece (Fig. 2A): a.
  • Page 13 IN220 Mortise Lock 2B Prepare 8200 Lock Body* *If 8200 is type of lock being installed 1. Reverse Lock Hand Red surface of locking piece must face the outside/locked side of door. To rotate locking Right Hand piece (Fig. 2B1): Lock Shown a.
  • Page 14 IN220 Mortise Lock 3 Install Door Position Switch (DPS) 1. Push wires through raceway toward lock prep. 2. Push DPS firmly into place by hand. Note: DO NOT TAP SWITCH WITH ANY TOOL. 3. Install magnet into door frame. Push firmly into place by hand.
  • Page 15 IN220 Mortise Lock 4 Install Lock Body Note: Do not pull the lock into the pocket using the harness alone. Ensure that the wire harness is not pinched between the lock and the mortise pocket. 1. Feed the wire harness into the mortise pocket and through inside preparation hole as depicted in Figure 4.
  • Page 16 Note: Do not attempt to tighten all the way. IMPORTANT: Position cylinder so that the SARGENT logo is positioned correctly. 4. Verify that orientation of cylinder has the SARGENT logo as depicted in Fig. 5A. 5. Hand tighten the cylinder clamp screw with Phillips screwdriver to prevent unscrewing of the cylinder (Fig 5C).
  • Page 17 IN220 Mortise Lock 6 Assemble Outside Trim 1. With outside lever horizontal, insert the mounting posts through outside of door and lock body. Make certain the lever spindle is properly engaged inside the lock body (Fig 6A). 2. On the inside of the door, insert spindle into square hole of mortise lock (Fig 6B).
  • Page 18 IN220 Mortise Lock 7 Install Inside Rose and Inside Lever Assembly 1. Place inside rose flush against door surface and rotate first counter-clockwise to seat the threads, then clockwise to securely tighten. 2. Slide lever onto spindle until fully seated. Be sure handle is horizontal and facing the hinge side of the door.
  • Page 19 IN220 Mortise Lock 8 Install Thumb Turn 1. Insert thumb turn into preparation hole and engage slot in lock body. 2. Orient mounting plate so screw hole is vertical (aligned with preparation holes). 3. Secure plate with Phillips screw provided.
  • Page 20 IN220 Mortise Lock 10 Outside Reader and Mounting Plate Installation 1. Orient the reader so the LED lens is at the top. 2. Feed the cable/connector through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes.
  • Page 21 IN220 Mortise Lock 10 Outside Reader Installation (Continued) 4. Next feed the cables/connectors through the inside mounting assembly (and gasket if required*). 5. Insert and partially tighten (2) through-bolts prior to installation of connectors. NOTE: Cable lengths exaggerated for illustrative purposes.
  • Page 22 IN220 Mortise Lock Installation of Connectors DPS (4-pin) CAUTION - Do not touch or allow debris to enter connector contacts. Secure the following connectors to their respective terminals (Fig. 11A, B): A. Secure the 4-pin DPS connector. B. Secure the 10-pin lock body assembly connector.
  • Page 23 IN220 Mortise Lock 12 Installation of Inside Module Component Assembly 1. Insert top tabs of controller into slots on mounting plate (Fig. 12A, B). 2. Ensure proper alignment of board-to-board connectors while pivoting bottom of controller toward door until tab on bottom snaps securely into place on mounting plate.
  • Page 24 IN220 Mortise Lock 13 Inside Cover Installation 1. Assemble cover by hooking top edge on inside mounting plate. 2. Carefully press bottom of cover toward door without pinching wires. 3. Secure the cover with the security allen wrench. Inside of Door...

  • Page 25: Operational Check

    IN220 Mortise Lock Operational Check For 7976- and 7978-function mortise locks with cylinders: 1. Insert key into cylinder and rotate. There should be no friction against lock case, wire harness or any other obstructions. 2. Check that the key retracts the latch: the key should rotate freely.
  • Page 26 IN220 Mortise Lock Notes 1-800-810-WIRE • www.sargentlock.com • A8204B...
  • Page 28 New Haven, CT 06511 USA 800-810-WIRE (9473) • www.sargentlock.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications. The company’s customer base includes commercial construction, institutional, and industrial markets.
