ADP5140-EVALZ User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
3 C1, C2, C32
8 C3 to C5, C11, C12, C16,
C33, C34
12 C6, C7, C13, C14, C17,
C19 to C22, C24, C30,
C31
1 C8
2 C9, C10
1 C15
2 C18, C29
1 C23
1 C25
7 C26 to C28, C35 to C38
3 D1 to D3
1 D4
36 J1, J3 to J9, J11 to J20,
J22 to J35, J37, S1 to S3
3 J2, J10, J21
1 J36
2 L1, L2
2 L3, L4
1 L5
1 L6
1 P1
1 R1
7 R3, R4, R19 to R23
6 R5, R9 to R13
1 R6
1 R7
4 R8, R24 to R26
1 R14
5 R15 to R18, R29
46 TP1 to TP41, TP44 to
TP48
1 U1
Description
Capacitors, 0.1 µF, 16 V, 0603
Capacitors, 47 µF, 6.3 V, 1210
Capacitors, 10 µF, 6.3 V, 0805
Capacitor, 10 nF, 50 V, 0603
Optional capacitors, 1210
Capacitor, 22 µF, 10 V, 1206
Capacitors, 4.7 µF, 6.3 V, 0603
Capacitor, 4.7 µF, 16 V, 0805
Capacitor, 0.47 µF, 16 V, 0603
Capacitors, 1 µF, 16 V, 0603
Light emitting diodes (LEDs), red, 1.7 V, 20 mA
Optional diode, SOD-123 package
2-position header connectors, 2.54 mm pitch,
through-hole, gold
3-position header connectors, 2.54 mm pitch,
through-hole, gold
4-position terminal block header, female socket, 5.08 mm
pitch, 90°, right angle, through-hole
Chip inductors, 0.68 µH, saturation current (I
resistance = 37 mΩ
Chip inductors, 0.47 µH, I = 6.1 A, dc resistance = 27 mΩ
SAT
Chip inductor, 100 nH, I = 13 A, dc resistance = 9 mΩ
SAT
Chip inductor, 4.7 µH, I = 2.2 A, dc resistance = 200 mΩ
SAT
10-position receptacle connector, 2.54 mm pitch,
through-hole, tin
Resistor, 162 kΩ, 1%, 0603
Resistors, 0 Ω, 0603
Resistors, 10 kΩ, 1%, 0603
Resistor, 30 mΩ, 1%, 0603
Resistor, 16.5 kΩ, 1%, 0603
Resistors, 5.11 kΩ, 1%, 0603
Resistor, 15 kΩ, 1%, 0603
Optional resistors, 0603
1-position header connectors, through-hole, gold
Power management IC for automotive application
Rev. 0 | Page 9 of 10
Manufacturer
Murata
Murata
Murata
Murata
Murata
Murata
Murata
Murata
Murata
Murata
LUMEX
ON Semiconductor
Wurth
Wurth
Phoenixus
) = 5.1 A, dc Murata
SAT
Murata
TDK
Murata
Wurth
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Wurth
Analog Devices, Inc.
UG-1861
Part Number
GCM188R71C104KA37
GCM32ER70J476KE19L
GCM21BR70J106KE22
GCM188R71H103KA37D
Optional
GCM31CR71A226KE02
GCJ188C70J475KE02
GCM21BR71C475KA73
GCM188R71C474KA55
GCM188R71C105KA64
SML-LX0603SRW-TR
Optional
61300211121
61300311121
1786420
DFE252012PD-R68M
DFE252012PD-R47M
TFM252012ALMAR10MTAA
DFE252012PD-4R7M
690367181072
CRCW0603162KFKEA
CRCW06030000Z0EA
CRCW060310K0FKEA
RCWE060330L0FQEA
CRCW060316K5FKEA
CRCW06035K11FKEA
CRCW060315K0FKEA
Optional
61300111121
ADP5140WFSACCZ-R7
