Muse ML-35 BT Manual

LOCATION OF CONTROLS

1. Adjust the light brightness; pause/start the cycle of the ambience color light
2. alarm 1 indicator
3. alarm 2 indicator
4. SNZ. Snooze indicator
5. Light
6. LED display
7. Light ON/OFF button
8. POWER ON indicator
9. Bluetooth indicator
10. Sleep indicator
11. Nap indicator
12. Battery compartment
13. Alarm 2
    volume down
14. volume up
    Alarm 1
15. : Dimmer light intensity of the screen / SNOOZE: Interval alarm repetition / Memorization / Setting the clock
16. AUX IN jack
17. USB CHARGING: USB port for charging
18. : NAP
    : To fall asleep with the radio, AUX and Bluetooth mode.
19. Setting down
    HR.: Hour setting
20. MIN.: Minute setting
    Setting up
21. Auto scan and preset radio stations
    Play/Pause
22. To turn unit on / off
    SOURCE: To select FM, AUX or BLUETOOTH mode

POWER SUPPLY

AC: 100-240V ~ 50/60Hz

DC: 2x1.5V, battery type AAA/R03/UM4 (not provided) for back-up.

For optimal performance, alkaline batteries are recommended.

These batteries must be replaced every six months.

1. Insert the plug of power cord into a standard wall outlet.
2. Install the backup batteries in their compartment. Use only the size and type of batteries specified. Respect the polarity indicated in the compartment. Improper polarity can cause damage to the device.

• Do not attempt to recharge the batteries, they can catch fire or explode.
• In order to avoid leakage, always remove the batteries when unit will not be used for a long period of time. Do not mix different types of batteries or old batteries with new ones.

Backup System: All settings are memorized, however, the clock time could occasionally need to be readjusted. In case of power failure, if backup batteries are not installed, the screen will flash to indicate this power failure and the necessity to redo your settings.

LIGHTING

Main light (White light)

1. Press once to turn on the light.
2. Press repeatedly to adjust the brightness level of the white light (from 01 to 20).

Color light

3. Press twice to turn on the color light, then it will start to cycle different colors. Each color will be displayed for 5 seconds.
4. Press to pause the current color, press again to resume the cycle.
5. Press button thrice to turn off the light.

SETTING THE TIME

1. In standby mode, press and hold button, the display will flash. Set the time with HR. hour and/ or MIN. minutes.
2. Press again to confirm.

NOTE: If during the adjustment time no key is activated in 5 seconds, the current display will be automatically stored.

TURNING ON / OFF THE UNIT

In standby mode, press once to turn on the unit. Press and hold for 2 seconds to turn off the unit.

SELECTING FUNCTION

When the unit is ON, press SOURCE button repeatedly to select the desired function in cycle: FM, Bluetooth (), AUX ().

LISTENING TO THE RADIO

When the unit is on, press SOURCE button repeatedly to select FM mode. The display will show current frequency for a few seconds and change to clock time.

Manual search

1. In FM mode, Choose your radio station with or .
2. Adjust the volume by or to the desired level.
3. For best reception, extend the FM wire antenna.
4. To stop listening to the radio, press and hold to turn the unit off.

Automatic search

Press and hold for few seconds or , the automatic search locates strong stations. A station with a weak signal can be set manually by repeatedly pressing or .

NOTE: During the search operation, the sound level is automatically muted.

Preset stations

This unit can store 20 FM stations.

Manual storage

1. Select a radio station manually or in automatic search.
2. Long press , "P 01" blinks on the screen.
3. Press or to select a channel.
4. Press to save it.
5. Repeat steps 1-4 to store other stations.

Automatic storage

In FM mode, press and hold for few seconds and the unit will automatically save the first 20 FM stations. When you store on a channel already been preset, the previous station will automatically be cleared and replaced by the new station.

Listening to station presets

Press and repeat the operation as many times as necessary to select your station.

Press or to adjust the sound level.

CONNECTING AUXILIARY SOURCE

1. Connect your auxiliary source (e.g. mp3 player) to the AUX IN jack on unit (cable included).
2. Press SOURCE button on unit repeatedly to select AUX mode. Aux indicator lights up, The display will show "" for a few seconds and change to clock time.
3. Start playback from your auxiliary source.
4. Adjust the volume to desired level.
5. To stop playback, disconnect your auxiliary source from the AUX IN jack.

BLUETOOTH FUNCTION

The Bluetooth^® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by New One S.A.S is under license. Other trademarks and trade names are those of their respective owners.

Hereby, NEW ONE S.A.S, declares that this MUSE ML-35 BT is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The declaration of conformity may be consulted at www.muse-europe.com

Pairing a Bluetooth Device

1. When the unit is ON, Press SOURCE button repeatedly to select Bluetooth mode. The display will show "" for a few seconds and change to clock time. The Bluetooth indicator will start to blink on display which it is in pairing mode.
2. On the Bluetooth device, enable Bluetooth and select "ML-35BT" from the Device List. (Refer to the user manual of the device to be connected for detailed operations.) If the Bluetooth device prompts for a pass code, use "0000". Some Bluetooth devices will ask you to accept the connection. You will hear an indication sound when pairing is successful. The Bluetooth indicator stops blinking and stays lit.

Tip: If you want to connect your Bluetooth speaker to another Bluetooth audio device, you need to disconnect current device first and follow the steps above to make a new connection.

• On some devices such as computers, once paired you must select the unit from the Bluetooth menu and choose "Use as Audio Device (stereo)" or similar.
• Pairing remains intact when the unit and/or your Bluetooth device is taken out of communication range. An active connection will be reestablished when your Bluetooth device returns within range.
• When the unit is turned on again, it will automatically try to reconnect with the most recently paired Bluetooth device.

Using a Bluetooth Device

1. With a unit paired (see previous section), operate your Bluetooth device and its sound will be heard through the ML-35BT's speakers.
2. Press the button to pause playback. Press again to resume playback.
3. Select desired track with / .
4. Adjust the volume using the / Volume buttons. You can also adjust the volume on the device to which you are paired.

SETTING THE ALARM AND THE ALARM MODE

1. In standby mode, press and hold for a few seconds, the display blinks.
2. Press HR. and / or MIN. to set the time of wake up.
3. Press then press or to select the source of wake up: buzzer, radio or Bluetooth.
4. When the alarm 1 indicator is blinking, press repeatedly to set the progressive light trigger time: 05 > 10 > 15 > 20 > OFF.
   (For example, if "05" is selected, the progressive light will turn on 5 minutes before the alarm time is reached, If "OFF" is selected, the white light will not switch on at wake up time)
5. Press to confirm, alarm 1 indicator will light up.

Note:

• The corresponding alarm indicator blinks when the alarm function is activated.
• When the alarm time is reached, the alarm volume will increase gradually.
• When Bluetooth () is the wake-up source, make sure your Bluetooth device (e.g. Smartphone) is the most recently paired Bluetooth device to ML-35BT, and the Bluetooth function is enabled on your Bluetooth device. When the alarm time is reached, the unit will automatically reconnect with your Bluetooth device and the songs in your Bluetooth device will start to play automatically.

* Same procedure applies for alarm 2 with button.

STOPPING THE ALARM

Alarm repetition

Press SNOOZE. The alarm stops and will sound again 9 minutes later, alarm 1 indicator blinks and snooze indicator lights up during snooze time.

Alarm stop

Press or . The alarm 1 will sound again the next day at the same time, alarm 1 indicator lights up.

Alarm Cancellation

In Standby mode, press to cancel the alarm1 permanently. The alarm1 indicator lights off.

Note: Same procedure applies for Alarm 2 with button.

SLEEP FUNCTION

When unit is ON, press to select 120-90-60-30-15-10 or 5 minutes of listening. The sleep indicator lights up. The unit will automatically turn off after the specified time is reached. To cancel the sleep function, repeatedly press button until "OFF" is displayed, or Long press button to turn off the unit.

Note: If the white light or color light is ON during sleep function, the light will turn off when the sleep time is reached.

NAP FUNCTION

This function wakes you up after a short period of time. Only the buzzer may be selected.

1. In standby mode, press to select 120-90-60-30-15-10 or 5 minutes for your nap. The indicator lights up.
2. To stop the alarm, press or .
3. To cancel the function, press repeatedly until OFF is displayed.

DIMMER

Press to select the brightness of the screen: high, low, or off.

USB CHARGING

This unit is equipped with a built-in USB charging port (Output: 5V 1A) for recharging your mobile device (e.g. Smartphone, tablet, etc. )

Simply plug the USB charging cable (not included) into the USB charging port and connect it to your mobile device.

TECHNICAL SPECIFICATIONS

POWER SUPPLY:

AC: 100-240V ~ 50/60Hz, 14W

DC: 3V 2x1.5V, Battery type: AAA/R03/UM4 (not included) for back up.

RADIO: FM: 87.5-108 MHz

BLUETOOTH

Bluetooth Version: V4.1

Bluetooth: 2.402-2.48GHz

RF Output power: 4 dBm

Working Distance: Up to 10 meters measured in open space (wall and structures may affect range of device)

Specifications are subject to change without notice.
