7.

ADJUSTMENTS

DIP1 Command 1-5 operation.
NOTE: it also sets operating mode of the
plugin cards connected on AUX.
DIP2 Motor installation position.
The installation position is intended by
viewing the automation from the side be-
ing examined.
DIP3 Restore automatic closing time.
DIP4 Automation status at power on.
Indicates how the control panel considers
automation when powered up.
DIP5 3 seconds pre ashing.
JR3 Automation type.
JR4 Incorporated radio receiver.
SO Reversal safety switch function.
6 4 Command 1-6 operation.
Description
Description
OFF
Step-by-step.
Central or right side.
50%
Open.
NOTE: with limit switches
installed, preferably
DIP4=OFF.
Disabled during opening.
Enabled only with automatic
closing with TC>3 s.
OFF
2 motors automation.
Disabled.
With the automation
bloc ed, if the contact 1-8
is open, it is possible to
activate the opening opera-
tion.
Closing.
7
ON
Opening.
Left side.
100%
Closed.
NOTE: if the automatic clos-
set ing function is not used,
preferably set DIP4=ON.
Enabled for both opening
and closing.
ON
1 motor automation.
Enabled.
With the automation
bloc ed, if the contact 1-8
is open, any operation is
impossible.
Stop.
