5.

COMMANDS

Command
1 5 N.O. STEP-BY-STEP
WITH AUTOMATIC
CLOSING
STEP-BY-STEP
WITHOUT AUTOMATIC
CLOSING
OPENING WITH
AUTOMATIC
CLOSING
OPENING WITHOUT
AUTOMATIC
CLOSING
1 6 N.C. SAFETY STOP
1 6 N.O. CLOSING
1 8 N.C. REVERSE
SAFETY CONTACT
1 9 N.C. STOP
1 9 N.O. HOLD-TO-RUN
FUNCTION
0 11 N.C. CLOSING PROXIMITY
LIMIT SWITCH
0 12 N.C. OPENING
LIMIT SWITCH
N.O. TRANSMITTERS
STORAGE AND
CANCELLATION
PRG
WARNING: make a jumper for all the N.C. contacts if not in use. The terminals with the same number
are equal.
Function
With DIP1=OFF and TC<MAX, the closing of the contact acti-
vates opening or closing operations in the following sequence:
open-stop-close-open.
NOTE: the stop is not permanent but lasts for a duration set
by TC.
With DIP1=OFF and TC=MAX, the closing of the contact acti-
vates opening or closing operations in the following sequence:
open-stop-close-open.
With DIP1=ON and TC<MAX, the closing of the contact acti-
vates the opening operation.
With DIP1=ON and TC=MAX, the closing of the contact acti-
vates the opening operation.
NOTE: once the automation stops, the closing of the contact
performs the opposite operation to the one performed before
stop.
With 6 4=ON, all operations are stopped and/or bloc ed
when the safety contact is opened.
With 6 4=OFF, the closing of the contact activates the clos-
ing operation.
The opening of the safety contact triggers a reversal of motion
(re-opening) during closing.
The opening of the safety contact stops the current operation.
The opening of the 1-9 contact enables the hold-to-run func-
tion.
- hold-to-run opening 1-5 [with DIP1=ON];
- hold-to-run closing 1-6 [with 6 4=OFF].
NOTE: any safety device, automatic closing and plug-in card
inserted in AUX is disabled.
With DIP2=OFF, after the contact has opened, the closing
movement stops on the mechanical stop.
With DIP2=ON, the opening of the contact stops the opening
operation.
With DIP2=OFF, the opening of the contact stops the opening
operation.
With DIP2=ON, after the contact has opened, the closing
movement stops on the mechanical stop.
WARNING: the BIXMR2 storage module must be inserted.
Transmitter storage:
- press the PRG ey (the SIG LED comes on),
- transmit the transmitter to be stored (the SIG LED ashes),
- wait 10 s to complete storage (the SIG LED goes out).
Transmitter cancellation:
- press the PRG ey for 3 sec (the SIG LED ashes),
- press the PRG ey for another 3 sec (the SIG LED ashes
quic ly).
Description
5 IP1982EN 2012-03-22
