9.

START-UP

WARNING WARNING The operations in point 4 are performed without safety devices. The operations in point 4 are performed without safety devices.
The trimmer can only be adjusted with the automation idle. The trimmer can only be adjusted with the automation idle.
1- Ma e a jumper for the N.C. safety contacts.
2- If installed, adjust the opening and closing stop limit switches.
NOTE: limit switches must be kept pressed until the operation has been completed.
3- Set TC=MAX.
Use DIP2 to set the installation position.
4- Switch on and chec that the automation is operating correctly with subsequent opening and closing
commands.
If installed, chec that the limit switches are activated.
5- Connect the safety devices (removing the relative jumpers) and chec they wor correctly.
6- If required, adjust the automatic closing time with the TC trimmer.
WARNING: the automatic closing time after a safety device has triggered depends on the DIP3 setting.
7- Set the desired opening and closing speed using the VA and VC trimmers.
8- Set the obstacle thrust with the R1 trimmer.
WARNING: after adjusting check that the working forces exerted by the door wings are compliant with
EN12453-EN12445 regulations.
9- Connect any other accessories and chec they operate correctly.
i
NOTE: in the event of servicing or if the control panel is to be replaced, repeat the start-up procedure.
IP1982EN 2012-03-22 10
