2. EC DECLARATION OF CONFORMITY

Manufacturer: DITEC S.p.A.
Address: via Mons. Ban , 3 21042 Caronno P.lla (VA) - ITALY
declares that the control panel E1HBOX (with receiver 433.92 MHz) is in conformity with the provisions of the
following EC directives:
R&TTE Directive 1999/5/EC;
EMC Directive 2004/108/EC;
Low Voltage Directive 2006/95/EC.
Caronno Pertusella, 01-09-2010
3.

TECHNICAL DATA

Power supply
F1 fuse
1 motor output
2 motors output
Accessories power supply 24 V 0.3 A
Temperature
Degree of protection
Memorizable
radio codes
Radio frequency
i
NOTE: the given operating and performance features can only be guaranteed with the use of DITEC
accessories and safety devices.

3.1 Applications

4. CONNECTION OF POWER SUPPLY

Before connecting the power supply, ma e sure the plate data correspond to that of the mains power supply.
An omnipolar disconnection switch with minimum contact gaps of 3 mm must be included in the mains supply.
Chec that upstream of the electrical installation there is an adequate residual current circuit brea er and a
suitable overcurrent cutout.
Use a H05RN-F 3G1,5 or H05RR-F 3G1,5 type electric cable and connect to the terminals L (brown), N (blue),
(yellow/green) in the automation.
Secure the cable using a special cable clamp.
Ma e sure there are no sharp edges that may damage the power supply cable.
Connection to the mains power supply, in the section outside the automation, is made with independent chan-
nels and separated from the connections to the control and safety devices.
IP1982EN 2012-03-22
E1HBOX
230 V~ 50/60 Hz
F1.6A
24 V 9 A max
24 V 2x5.5 A max
min -20 °C max +55 °C
IP24D
200
433.92 MHz
4
