Mechanical Installation
Figure 3-1 Commander SK dimensions
Ca
Cb
C
D
Mounting holes: 4 x M4 holes
Table 3-1 Commander SK dimensions
Drive
A
size
mm
in
mm
A
140 5.51 154 6.06
B
190 7.48 205 8.07
C
240 9.45 258 10.16 70.5 2.78
On size A, the mounting feet are equal distance from the centre line of the drive.
On size B and C, the mounting feet are not an equal distance from the centre line of the
drive, hence the Ca and Cb dimensions.
*Size C is not DIN rail mountable.
