Safety Rating Mechanical
Information Data Installation
Status Modes
Left hand
display
Speed Indications
Display
Mnemonic
Load indications
Display
Mnemonic
5.4

Saving parameters

Parameters are automatically saved when the
from parameter edit mode to parameter view mode.
5.5

Parameter access

There are 3 levels of parameter access controlled by Pr 10. This determines which
parameters are accessible. See Table 5-1.
The setting of the user security Pr 25 determines whether the parameter access is read
only (RO) or read write (RW).
Table 5-1
Parameter access (Pr 10)
Commander SK Getting Started Guide
Issue Number: 1
Electrical Keypad and
Parameters
Installation Display
Status
The drive is enabled and ready for a start command. The
Drive ready
output bridge is inactive.
The drive is inhibited because there is no enable command,
Drive inhibited or a coast to stop is in progress or the drive is inhibited during
a trip reset.
The drive has tripped. The trip code will be displayed in the
Drive has tripped
right hand display.
DC injection braking DC injection braking current is being applied to the motor.
Explanation
Drive output frequency in Hz
Motor speed in rpm
Machine speed in customer define units
Explanation
Load current as a % of motor rated load current
Drive output current per phase in A
Parameters accessible
L1 Pr 01 to Pr 10
L2 Pr 01 to Pr 60
L3 Pr 01 to Pr 95
www.controltechniques.com
Quick Start
Diagnostics Options
Commissioning
Explanation
MODE key is pressed when going
M
Parameter UL Listing
List Information
17
