Control Techniques Commander SK Getting Started Manual page 27

Safety Rating Mechanical
Information Data Installation
No Function
25 Security set-up
Used to set-up a user security code. See section 5.6 Security codes on page 18.
No Function
26 Not used
No Function
27 Power up keypad reference
0: keypad reference is zero
LASt:keypad reference is last value selected before the drive was powered down
PrS1:keypad reference is copied from preset speed 1
No Function
28 Parameter cloning
nO: do nothing
rEAd:program the drive with the contents of the SmartStick
Prog:program the SmartStick with the current drive settings
boot: SmartStick becomes read only. The contents of the SmartStick will be copied to
the drive every time the drive is powered up.
Parameter cloning is initiated by pressing the
mode after Pr 28 has been set to rEAd, Prog or boot.
If parameter cloning is enabled when no SmartStick is fitted to the drive, the drive's
NOTE
display will flash FAIL twice before changing back to nO.
No Function
29 Load defaults
nO: defaults are not loaded
Eur: 50Hz default parameters are loaded
USA: 60Hz default parameters are loaded
Default parameters are set by pressing the
mode after Pr 29 has been set to Eur or USA.
When default parameters have been set, the display will return to Pr 01 and Pr 10 will be
reset to L1.
The drive must be in a disabled, stopped or tripped condition to allow default parameters
NOTE
to be set. If default parameters are set while the drive is running, the display will flash
FAIL twice before changing back to nO.
No Function
30 Ramp mode select
0: Fast ramp selected
1: Standard ramp with normal motor voltage selected
2: Standard ramp with high motor voltage selected
3: Fast ramp with high motor voltage selected
Fast ramp is linear deceleration at programmed rate, normally used when a braking
resistor is fitted.
Standard ramp is controlled deceleration to prevent DC bus over-voltage trips, normally
used when there is no braking resistor fitted.
Commander SK Getting Started Guide
Issue Number: 1
Electrical Keypad and
Parameters
Installation Display
nO, rEAd, Prog, boot
www.controltechniques.com
Quick Start
Diagnostics Options
Commissioning
Range
0 to 999
Range
Range
0, LASt, PrS1
Range
MODE key on exit from parameter edit
M
Range
nO, Eur, USA
MODE key on exit from parameter edit
M
Range
0 to 3
Parameter UL Listing
List Information
Defaults Type
0 RW
Defaults Type
Defaults Type
0 RW
Defaults Type
no RW
Defaults Type
no RW
Defaults Type
1 RW
27
