Control Techniques Commander SK Getting Started Manual page 29

Safety Rating Mechanical
Information Data Installation
No Function
35 Digital output function (terminal B3)
n=0: At zero speed
At.SP: At speed
Lo.SP: At minimum speed
hEAL: Drive healthy
Act: Drive active
ALAr: General drive alarm
I.Lt: Current limit active
At.Ld: At 100% load
USEr: User programmable
This parameter is automatically changed by the setting of Pr 12. When Pr 12
NOTE
automatically controls the setting of this parameter, this parameter cannot be changed.
A change to this parameter is only implemented if the drive is disabled, stopped or
NOTE
tripped and the
See the Commander SK Advanced User Guide.
No Function
36 Analog output function (terminal B1)
Fr: Voltage proportional to motor speed
Ld: Voltage proportional to motor load
A: Voltage proportional to output current
Por: Voltage proportional to output power
USEr: User programmable
A change to this parameter is only implemented if the drive is disabled, stopped or
NOTE
tripped and the
See the Commander SK Advanced User Guide.
No Function
37 Maximum switching frequency
3: 3kHz
6: 6kHz
12: 12kHz
18: 18kHz
No Function
38 Autotune
0: No autotune
1: Non-rotating static autotune
2: Rotating autotune
When a rotating autotune is selected, the drive will accelerate the motor up to
maximum speed in Pr 02.
WARNING
The motor must be at a standstill before a non-rotating autotune is initiated.
NOTE
The motor must be at a standstill and unloaded before a rotating autotune is initiated.
NOTE
Commander SK Getting Started Guide
Issue Number: 1
Electrical Keypad and
Parameters
Installation Display
n=0, At.SP, Lo.SP, hEAL,
Act, ALAr, I.Lt, At.Ld, USEr
STOP/RESET key is pressed for 1s.
Fr, Ld, A, Por, USEr
STOP/RESET key is pressed for 1s.
3, 6, 12, 18 kHz
www.controltechniques.com
Quick Start
Diagnostics Options
Commissioning
Range
Range
Range
Range
0 to 2
Parameter UL Listing
List Information
Defaults Type
n=0 RW
Defaults Type
Fr RW
Defaults Type
3 RW
Defaults Type
0 RW
2
/
3
29
