6.4

Diagnostic parameters

The following read only (RO) parameters can be used as an aid to fault diagnosis on the
drive. See Figure 8-1 Diagnostics logic diagram on page 40.
No
81 Reference selected
82 Pre-ramp reference
83 Post-ramp reference
84 DC bus voltage
85 Motor frequency
86 Motor voltage
87 Motor speed
88 Motor current
89 Motor active current
90 Digital I/O readword
91 Reference on indicator
92 Reverse selected indicator
93 Jog selected indicator
94 Analog input 1
95 Analog input 2
