Parameter List

Par Description
01 Minimum set speed (Hz)
02 Maximum set speed (Hz)
03 Acceleration rate (s/100Hz)
04 Deceleration rate (s/100Hz)
05 Drive configuration
06 Motor rated current (A)
07 Motor rated speed (rpm)
08 Motor rated voltage (V)
Motor power factor (cos ϕ)
09
10 Parameter access
11 Start/Stop logic select
12 Brake enable
13
Not used
14
15 Jog reference (Hz)
16 Analog 1 input mode (mA)
17 Enable negative preset speeds
18 Preset speed 1 (Hz)
19 Preset speed 2 (Hz)
20 Preset speed 3 (Hz)
21 Preset speed 4 (Hz)
22 Load display units
23 Speed display units
24 Customer defined scaling
25 Security set-up
26 Not used
27 Power up keypad reference
28 Parameter cloning
29 Load defaults
30 Ramp mode select
31 Stopping mode select
32 Variable torque select
33 Catch a spinning motor select
34 Terminal B7 mode select
35 Digital output function (terminal B3)
36 Analog output function (terminal B1)
37 Maximum switching frequency (kHz)
38 Autotune
39 Motor rated frequency (Hz)
40 Number of poles
41 Voltage mode selector
42 Low frequency voltage boost (%)
43 Serial communications baude rate
44 Serial address
45 Software version
46 Brake release current threshold (%)
47 Brake applied current threshold (%)
48 Brake release frequency (Hz)
49 Brake applied frequency (Hz)
50 Pre-brake release delay (s)
51 Post brake release delay (s)
52 Fieldbus node address
53 Fieldbus baude rate
54 Fieldbus diagnostics
55 Last trip
