EVAL-ADM2867EEBZ

ORDERING INFORMATION

BILL OF MATERIALS

Table 4. EVAL-ADM2867EEBZ Bill of Materials
Qty Reference Designator
10 A, B, DE, INVD, INVR, RE,
RxD, TxD, Y, Z
5 C1, C5, C7 to C9
2 C2, C3
2 C4, C12
2 C6, C13
1 C10
1 C11
2 E1, E2
2 E4, E5
2 GND1, GND2
1 J1
4 LK1, LK4, LK5, LK8
1 LK2
1 LK3
5 LK6, LK7, LK9 to LK11
5 P1 to P3, P7, P8
3 R1, R3, R7, R8
1 R2
1 R4
1 R5
1 R6
1 R14
4 R10 to R13
2 RT1, RT2
1 U1
1 U2
1 U3
3 VCC, VIO, VISO
User Guide
Description
Test points, yellow
Capacitors, 0.1 µF, 0402
Capacitors, 1 µF, 0805
Capacitors, 10 µF, 0805
Capacitors, 390 pF, 0603
Capacitor, 15 pF, 0402
Capacitor, 10 µF, 0603
Ferrite beads, 0402
Ferrite beads, 0603, 600 Ω at 100 MHz
Test points, black
Coaxial, straight SMA connector
6-pin (3 × 2), 0.1 inch headers and shorting block
8-pin (4 × 2), 0.1 inch header and shorting block
3-pin (3 × 1), 0.1 inch header and shorting block
2-pin (1 × 2), 0.1 inch headers and shorting block
Three-way terminal blocks
Resistors, 0 Ω, 0603
Resistor, 20 kΩ, 0603
Resistor, 13 kΩ, 0603
Resistor, 18.2 kΩ, 0603
Resistor, do not install, 0603
Resistor, 22.1 kΩ, 0603
Resistors, do not install, 0805
Resistors, 120 Ω, 0805
Low power, 1 kHz to 20 MHz oscillator
Low noise CMOS LDO
25 Mbps, 5.7 kV signal and power isolated RS-485
transceiver
Test points, red
Rev. 0 | Page 11 of 12
Manufacturer Part Number
Keystone Electronics 36-5004-ND
Kemet C0402C104K4RACTU
Murata GCM21BR71E105KA56L
TDK C2012X5R1E106K085AC
AVX Corporation 0603YC391KAT2A
Murata GCM1555C1H150FA16D
TDK C1608X5R1A106M080AC
Murata BLM15HD182SN1D
Murata BLM18HE601SN1D
Components Corporation TP-105-01-00
TE Connectivity 5-1814832-1
Multicomp 2213S-06G
Multicomp 2213S-08G
Molex 22-28-4033
Harwin M20-9990246
Wurth Elektronik 691131710003
Vishay CRCW0603000ZRT1
Panasonic ERJ-3EKF2002V
Panasonic ERJ-3EKF1302V
Panasonic ERJ-3EKF1822V
Not applicable Not applicable
Panasonic ERJ-3EKF2212V
Not applicable Not applicable
Panasonic ERJ-P6WF1200V
Analog Devices LTC6900IS5#PBF
Analog Devices ADP7104ARDZ-R7
Analog Devices ADM2867EBRNZ
Components Corporation TP-105-01-02
UG-1677
