Replace/Install Cylinder

1. Remove cylinder:
A. Repeat previous steps for removing the exterior lever handle.
B. Remove cylinder.
2. Install new cylinder:
A. Insert cylinder in exterior lever.
B. Insert key in cylinder; rotate the key 90° clockwise.
C. Push handle in allowing holes for set screw to align.
D. Insert set screw and tighten by turning set screw counter-clockwise.
E. Verify that new cylinder fits and rotates freely.
F. Test operation of the new cylinder/key.
