INSTALLATION
12
► Engage the hook on the lower side of the base plate
in the hole (red arrow) on the lower side of the fan
housing cover.
!
The guides for the fan unit are located in the
upper area.
14
► Carefully place the fan unit into the guides (red arrow)
of the fan housing.
!
Do not tilt the fan when inserting it so as not to
damage the contacts.
An audible click confirms that the fan unit is correctly

inserted.
20
13
► Press the cover of the fan housing in the upper area
onto the holder (green arrow) on the base plate of the
fan housing.
!
The locking button (red arrow) audibly engages
between the guides for the fan unit.
15
AC 230 V
1
0
1 0
► Make sure that the fan is able to roate freely once
switched on.
► Switch on the power supply.
• DC 12 V: When the power supply is switched on, the
fan runs (with switch control, the external switch is
used to switch on and off).
• AC 230 V: Switch the Pulsar Basic on. The switch is
located in the left side of the fan housing. Push it to
position 1.
Exhaust fan Pulsar Basic | Installation and operating instructions
6

Cleaning and care

CAUTION: Rotating parts on the fan lead to
injuries.
• Before working on electrical equipment, discon-
nect all affected equipment from the power sup-
ply (switch at the bottom left of the control unit).
CAUTION:
Cleaning by children and persons with limited
abilities may result in injury to parts of the body
and/or malfunction of the ventilation system!
• The Pulsar Basic must not be operated and
cleaned by children and/or persons who, due to
their physical, sensory or mental capabilities, in-
experience or lack of knowledge, are not safely
able to do so, unless they are supervised by a
person responsible for their safety or have been
instructed by him/her on how to operate the ven-
tilation unit.
The Pulsar Basic is virtually maintenance-free. The neces-
sary cleaning and maintenance work can be carried out by
the user after a short instruction.
The measures and intervals listed here are recommenda-
tions by inVENTer GmbH to maintain the functional and
performance capability of your Pulsar Basic.
Depending on your needs and/or air quality, your personal
cleaning schedule may vary from these recommendations.
Time span Assembly Maintenance measure
Clean the surface with a
Monthly Fan housing
damp cloth.
Semiannual Fan unit  22
Exhaust fan Pulsar Basic | Installation and operating instructions
CLEANING AND CARE
Cleaning agents:
The Pulsar Basic exhaust fan has a plastic surface that
is sensitive to scratches. Do not use cleaning agents
containing sand, soda, acid or chlorine to avoid damaging
the surface.
A commercial detergent in warm water can be used to
clean the surfaces.
Procedure:
► Switch on the power supply.
• AC 230 V: Disconnect the exhaust fan Pulsar Basic
at the switch. The switch is located in the left side of
the fan housing. Push it to position 0.
• DC 12 V: Interrupt the power supply at the mains
fuse or at the external switch.
1
► Reach behind the fan unit with both hands.
► Pull the fan unit forward off the fan housing.
!
Hold the fan unit firmily so it does not fall to the
floor when removed.
21
