iTero Element® 5D Plus User manual
2

Getting started

2.1

Assembling the iTero Element 5D Plus scanner

The scanner packaging is designed in a way that provides a simple and easy assembly process.
Follow the instructions below to assemble the scanner.
Contact iTero Support for additional help.
A 2x Allen keys
(in the white foam on top of the post)
B Post
C Wheel base
D Upper handle
(in the accessory box)
E Main handle
(in the accessory box)
F New-sleeve basket
(in the accessory box)
G Cradle
H Full HD touch-screen computing unit
I Wand
J Power cable
K Webcam
L Power switch
© 2020 Align Technology, Inc. All rights reserved. 9
