iTero Element® 5D Plus User manual
3. If required, you can tap
4. Tap
to confirm the trimming.
The selected area is removed.

Figure 160: Selected area has been removed

9.9

Working with the Die Separation tool

The die separation is created automatically, according to the position of the green hint point, which must be located
on the center of the prepped tooth after scanning.
If required, the die separation area can be edited or created manually.
To display the die separation:
1. After scanning the prepped tooth, ensure that the green hint point is centered on the prepped tooth. Move it
manually, if required.
© 2020 Align Technology, Inc. All rights reserved.
to undo the trimming.
141
