iTero Element® 5D Plus User manual
Test
Immunity from voltage dips, short
interruptions and voltage variations
Emission (per ETSI EN 301 489-1, ETSI EN 301 489-17)
Conducted emissions on mains
terminals in freq. range 150 kHz - 30
MHz
Radiated emissions
in freq. range 30 - 6000 MHz
Harmonic current test
Flicker tests
Immunity (per ETSI EN 301 489-1, ETSI EN 301 489-17)
Immunity from Electrostatic
discharge (ESD)
Immunity from radiated
electromagnetic fields
© 2020 Align Technology, Inc. All rights reserved.
Standard Class / Severity level
IEC 61000-4- On AC mode (240 V @ 50 Hz,
11 / 100 V @ 50 Hz): 0 % - 0.5 cycle
EN 61000-4-11 & 1 cycle;
70% - 25 cycles; 0% - 250
cycles;
On AC mode (220 V @ 60 Hz):
0 % - 0.5 cycle & 1 cycle;
70% - 30 cycles; 0% - 300
cycles
ETSI EN 301 Group 1 Class B
489-1; 230 VAC mains
ETSI EN 301
489-17 /
EN 55032
ETSI EN 301 Class B
489-1;
ETSI EN 301
489-17 /
EN 55032
ETSI EN 301 230 VAC mains
489-1;
ETSI EN 301
489-17 /
EN 61000-3-2
ETSI EN 301 230 VAC mains
489-1 /
EN 61000-3-3
EN 61000-4-2 4 kV contact discharge
8 kV air discharge
EN 61000-4-3 3.0 V/m,
80 MHz ¸ 6.0 GHz,
80% AM, 1 kHz
Test
results
Complies
Complies
Complies
Complies
Complies
Complies
Complies
