Figure 9: Removing The Wand From The Cradle - iTero Element 5D Plus User Manual

15. Secure the power cable (J) in the
two cable clips, making sure it is
fully inserted.
To remove the wand from the cradle, first pull the upper part of the wand towards you and then gently remove it from
the cradle.

Figure 9: Removing the wand from the cradle

12
16. For remote training or support
sessions, position the webcam
(K) on the screen and then
connect it to the USB port at the
back of the screen.
Note: The webcam must be
disconnected after each training
or support session.
iTero Element® 5D Plus User manual
17. Plug the power cable (J) into a
power outlet and then press the
Power button (L) to switch on the
scanner.
