Itero Element 5D Plus Wand; Figure 2: Rear View Of The Scanner; Figure 3: Itero Element 5D Plus Wand - iTero Element 5D Plus User Manual

iTero Element® 5D Plus User manual
Rear view of the scanner

Figure 2: Rear view of the scanner

1.3.1

iTero Element 5D Plus wand

Figure 3: iTero Element 5D Plus wand

Note: In order to protect the wand cable if too much pulling force is applied, the cable cap is designed to detach from
the wand. If this happens, gently reattach it.
© 2020 Align Technology, Inc. All rights reserved.
A Wand connector
B Diagnostics panel
(for Support purposes only)
C Upper handle
D New-sleeve basket
A Protective sleeve
B Touchpad
C Side buttons: Scan, on/off,
touchpad activation
D Vent cover
E Air vents
F Detachable wand cable with
USB connector
3
