iTero Element® 5D Plus User manual
a. On the legend, tap Scale.
The legend is expanded to display a list of range options, in millimeters.

Figure 154: Occlusal Clearance range options

b. Select the required scale.
c. The occlusal clearance is displayed according to the new scale.
4. If required, tap
screenshots and adding annotations, see section 9.11.
To display the occlusal clearance from the Viewer:
1. In the Viewer, tap
2. Select the arch for which to display the occlusal clearance.
The clearance between the opposing teeth is displayed, as well as a legend displaying the scale, in millimeters.
© 2020 Align Technology, Inc. All rights reserved.
to take a screenshot of the occlusal clearance. For more information on capturing
.
137
