  • Page 1 Bar code...
  • Page 2 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English RSAG2.025.8488SS...

  • Page 3: Table Of Contents

    Contents 1. Safety Precautions ............1 2. Introduction ..............8 2.1 Package Contents ..........8 2.2 Products View ............. 9 2.3 Remote Control ..........11 3. Installation Guide ............13 3.1 Precautions for Installation .........13 3.2 Wall Mount Kit Specifications (VESA) ....14 3.3 Installing the OPS (Optional) ......15 4.

  • Page 4: Safety Precautions

    Safety Precautions 1. Safety Precautions Declaration Any content and service accessed through this device, while only intended for individual non-commercial use, shall be the property of the applicable third party and subject to protection by regulations and laws on copyright, patent, trademark and other intellectual property rights. No part of such content and service may be modified, duplicated, published, uploaded, distributed, translated, marketed, or used to make and distribute products derived from it without the prior permission of the content owner or service provider.
  • Page 5 Safety Precautions This symbol alerts user about the presence of a ATTENTION dangerous voltage not isolated inside the product RISK OF SHOCK which can be sufficiently powerful to constitute a ELECTRIC risk of electrocution. Do not open the back cover. This symbol alerts user about the presence of In no case the user is allowed to operate inside the device.
  • Page 6 Safety Precautions Safeguards Please read the following safeguards for your device and retain for future reference. Always follow all warnings and instructions marked on the device. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference. 2.
  • Page 7 Safety Precautions 11. Servicing Do not attempt to service this device yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 12. Damage Requiring Service Unplug the device from the wall outlet and refer servicing to qualified service personnel under the following conditions: (a) When the power - supply cord or plug is damaged.
  • Page 8 Safety Precautions WR6CE User Manual...
  • Page 9 Safety Precautions WR6CE User Manual...
  • Page 10 Safety Precautions WR6CE User Manual...

  • Page 11: Introduction

    Introduction 2. Introduction 2.1 Package Contents Remote Control WR6CE × 1 Stylus × 2 Battery × 2 User Manual of the Device Wall Mount Bracket (Optional) Wall Mount Bracket Power Cord (It depends on the User Manual of Wireless Accessories bag (Optional) models, regions, or countries.) Cast ×...

  • Page 12: Products View

    Introduction 2.2 Products View 2.2.1 Front Panel | Control Panel Number Item Description When the mobile phone touches the device, it can achieve screen sharing through mobile phone NFC function. It is a USB interface, which can be used as the media playback interface of the device and the USB interface of embedded OPS module.
  • Page 13 Introduction 2.2.2 Rear Panel | I/O Panel Number Port Description HEADPHONE Audio out to Headphones HDMI OUT HDMI signal output, connect to an external device with HDMI input port HDMI IN HDMI signal input, connect to PC with HDMI output port, set- top box, or other video device Standard RJ45 Internet connection interface TOUCH...

  • Page 14: Remote Control

    Introduction 2.3 Remote Control Number Description Power Enter/exit standby Souce Switching signal source ▲/ Move focus up/down Move focus left/right Back Back to previous menu Volume down (-) Mute Activate/exit mute state Setting Open the Settings menu Blank Switch On/Off screen Confirm operation Freeze Once click: Keep the current screen...
  • Page 15 Introduction Battery replacement method Disconnect the battery cover from the remote control at the battery cover buckle and open the battery cover. Insert two AAA 1.5V alkaline batteries. Note that the positive (+) and negative (-) terminals of the batteries must match the positive (+) and negative (-) terminals in the battery case. 3.

  • Page 16: Installation Guide

    Installation Guide 3. Installation Guide 3.1 Precautions for Installation As shown in the figure below, leave a ventilation space around the device. When mounted on the wall: Please leave this space around the device. Do not install the device as shown below. Hinder air circulation Wall Insufficient ventilation will overheat the device and...

  • Page 17: Wall Mount Kit Specifications (Vesa)

    If attaching to other building materials, please contact your nearest dealer. Model VESA Spec. (A × B) Standard Screw (C × D) Quantity 65WR6CE 600 × 400mm M8 × 25 75WR6CE 600 × 600mm M8 × 25 86WR6CE 1000 ×...

  • Page 18: Installing The Ops (Optional)

    Installation Guide 3.3 Installing the OPS (Optional) Before installing and operating OPS, it is required to carefully read the instructions that come with OPS computer and this instruction manual. Installation Sequence 1. The touch screen is set to the "off" state, and the indicator light is off. 2.
  • Page 19 Installation Guide | A-B | ≤1mm Instructions for OPS terminal assembly tolerances (2) Instructions for assembly routes: a. Place the touch screen vertically or place the touch screen face-down stably, and make sure there is enough room for operation around the computer bracket on the back of screen. b.

  • Page 20: Making Connections

    Making Connections 4. Making Connections Number Port Description HEADPHONE Audio out to Headphones HDMI OUT HDMI signal output, connect to an external device with HDMI input port HDMI IN HDMI signal input, connect to PC with HDMI output port, set- top box, or other video device Standard RJ45 Internet connection interface TOUCH...
  • Page 21 Making Connections Connect to external audio device Digital audio output: connect to power amplifier via coaxial port, then connect power amplifer to speaker. Speaker Power amplifier Coaxial port Connect power amplifier to speaker Device port Connect to DP interface device Device port NOTE The supported signal formats of the DP port refer to Chapter 8 Appendix.
  • Page 22 Making Connections Connect to TOUCH interface device It is the touch screen interface used for an external PC as touch host. In both the HDMI and DP channels, the device is used as a touch unit by default When connecting, USB cables not longer than 1 meter should be used to connect with the external PC.
  • Page 23 Making Connections Connect to a network Enter the Settings menu and select the Network item. WIFI Wireless router Network port Network port in the wall The device can receive network signals directly through a Wireless router • The available wireless network list is automatically displayed when WIFI is selected. •...
  • Page 24 Making Connections You should purchase the OPS module which is applicable to the size of the device OPS. The size of OPS refers to the following figure: • Switching on/off the OPS After inserting OPS to the device, you turn on the device, change the signal source to enter OPS and stays on the OPS syetem interface.

  • Page 25: Getting Started

    Getting Started 5. Getting Started 5.1 Power On/Off Power Supply Plug • Connect the power cord of the device to a 100V to 240V AC outlet. • Press the standby button [ ] on the remote control in the power on state to switch the device to standby;...

  • Page 26: Using Gestures

    Using Vision Board 5.2 Using Gestures In any scene on the screen, touch the screen with five fingers to call up the shortcut menu. Number Function Description Annotation All-channel annotation Homepage One-click to return to Android homepage Signal source Open the list of signal source Volume Call out the volume adjustment interface Return...

  • Page 27: Serial Protocol

    Serial Protocol 6. Serial Protocol Serial port status The device can receive the serial port command sent by the external controller or OPS of the device. Refer to the following table for the specific command protocol: 1. Baud rate: 9600 2.
  • Page 28 Serial Protocol Protocol Protocol Length Command code Data Verify 　 header tail PC to X X X X 00 09 00 00 01 BB CC device Device to 00 00 01 X X X X 00 09 CD CD Set Time (H/M/S) The first XX is the Hour.
  • Page 29 Serial Protocol Protocol Length Command code Protocol tail 　 header PC to device Device to Switch on/off PC to device Device to PC to device Volume Device to Control Remark XX is the volume value. PC to device Bright- Device to ness Control Remark...

  • Page 30: Appendix

    Appendix 7. Appendix 7.1 Specification Features, appearance and specifications are subject to change without notice. Product name Hisense Interactive Digital Board Model 65WR6CE Size(mm) (W×H×D) excluding base 1488 x 889 x 95 Weight(kg) excluding base 33.0 Visual picture diagonal size (cm)
  • Page 31 Appendix Product name Hisense Interactive Digital Board Model 86WR6CE Size(mm) (W×H×D) excluding base 1955 x 1151 x 99 Weight(kg) excluding base 54.5 Visual picture diagonal size (cm) Power supply 100-240V 50/60Hz 4.3A Model TX7663BU58T TX7921AU64T 2.4~2.4835GHz Frequency Wireless Range LAN Module 5.15~5.85GHz...
  • Page 32 Appendix Signal formats supported by HDMI port RGB/60Hz 640 × 480, 800 × 600, 1024 × 768 YUV/50Hz 576i, 576p, 720p, 1080i, 1080p YUV/60Hz 480i, 480p, 720p, 1080i, 1080p YUV/24Hz 25Hz 30Hz 3840 x 2160, 4096 x 2160 YUV420/50Hz 60Hz 3840 x 2160, 4096 ×...

  • Page 33: Other Infomation

    Appendix 7.2 Other Infomation Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 34 Appendix WARNING:This set must not be opened unless by a qualified technician. WARNUNG: Dieses Set darf nur von einem qualifizierten Techniker geöffnet werden. VAROVÁNÍ: Toto zařízení nesmí být otevřeno, pokud není otevřeno kvalifikovanými techniky. VAROVANIE: Toto zariadenie neotvárajte, pokiaľ nemáte kvalifikovaného technika. AVERTIZARE: Nu deschideți acest echipament decât dacă...

  • Page 35: Certification And Compliance

    (2)l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Declaration of Conformity Trade Name: Hisense Model: 65WR6CE / 75WR6CE / 86WR6CE Responsible Party: Hisense USA Corporation Address: 7310 McGinnis Ferry Road, Suwanee, GA 30024 Telephone Number: 678-318-9060...

  • Page 36: Eu Declaration Of Conformity (Doc)

    *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2022/08/01 Signed by or for the manufacturer: Hisense Commercial Display Co.,Ltd. Address: No.218, Qianwangang Road, Economy& Technology Development Zone, Qingdao, China Title: Product manager...
  • Page 37 *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2022/08/01 Signed by or for the manufacturer: Hisense Commercial Display Co.,Ltd. Address: No.218, Qianwangang Road, Economy& Technology Development Zone, Qingdao, China Title: Product manager...
  • Page 38 *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2022/08/01 Signed by or for the manufacturer: Hisense Commercial Display Co.,Ltd. Address: No.218, Qianwangang Road, Economy& Technology Development Zone, Qingdao, China Title: Product manager...
  • Page 39 *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2022/08/01 Signed by or for the manufacturer: Hisense Commercial Display Co.,Ltd. Address: No.218, Qianwangang Road, Economy& Technology Development Zone, Qingdao, China Title: Product manager...
  • Page 40 *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2022/08/01 Signed by or for the manufacturer: Hisense Commercial Display Co.,Ltd. Address: No.218, Qianwangang Road, Economy& Technology Development Zone, Qingdao, China Title: Product manager...
  • Page 41 *The company reserves the right to install updated Software versions to improve the performance of the appliance. Place and date of issue (of this DoC): QingDao 2022/08/01 Signed by or for the manufacturer: Hisense Commercial Display Co.,Ltd. Address: No.218, Qianwangang Road, Economy& Technology Development Zone, Qingdao, China Title: Product manager...

  • Page 42: Troubleshooting

    Troubleshooting 8. Troubleshooting Before preparing for repair, check according to the table below to see if you can find the cause of the problem. If you strictly follow the instructions but still can’t resolve the problem, you can turn to professional servicemen for help.
