- Page 1 2021 Beyond An Immersive Experience User Manual Outdoor Series 65SOA25PT Issue Date: 31/08/2021 Copyright © 2021, All Rights Reserved.
-
Page 2: Table Of Contents
7.1.2 Disconnect power cable to A/C ..................... 10 7.1.3 Take out A/C........................... 10 7.1.4 Draw out tray and take out A/C ..................... 11 A/C installation ..........................11 7.2.1 Put A/C in the tray and fix it by rocker................... 11 Hisense B2B... - Page 3 Power on testing ............................15 safety testing ............................. 15 Power-on procedure .......................... 15 9.2.1 External power supply ........................15 9.2.2 Switch off power ..........................15 9.2.3 Display status test .......................... 15 Thermal management ........................... 16 Media player ............................16 OS................................16 Hisense B2B...
-
Page 4: Foreword
Please make sure installation and debugging is under the guidance of professional electrical engineers, software engineers to prevent any personal injury or equipment damage due to improper operation. 2 Safety Caution 2.1 Before Installation The product has air conditioner, please don’t lean during installation. 2.2 Power Voltage Hisense B2B... -
Page 5: Avoid Water
Please follow the instructions and install it firmly on the ground or bracket to prevent any LCD damage. 2.7 Cooling Performance There is air inlet & outlet in the rear of cabinet do not cover any object that will impact cooling performance. 2.8 Clean or Maintenance Shut down power before clean or maintenance. 2.9 Cleaning Hisense B2B... -
Page 6: Expert Engineer Required
Customer can use or change different cable length as per need, but the power cord diameter shall no less than the standard cable. When connecting the external power supply, please note wire connection correspondingly per the marks, ensure reliable earthing, must take guidance of professional electrical engineers. Hisense B2B... -
Page 7: Overall Size（Mm
Power Cable 4 Overall size（mm） Hisense B2B... -
Page 8: Technical Parameter
3840*2160 Brightness 2500cd/m2 Viewing angle 178° Contrast ratio 3000:1 IP rating IP65 Cooling system Air conditioner Working temp. -40℃～+50℃ Working Humidity 5%～100% Working Voltage 220V±10%，50HZ Consumption (max) 1200W 6 Diagram 6.1 3D Light sensor Speaker Cabin Air conditioner Hisense B2B... -
Page 9: Door Opening
6.2 2D Cable Entrance Speaker Rear door hole Air conditioner 6.3 Door opening Step 1 Step 2 Step 3 Hisense B2B... -
Page 10: Structure Inside
6.4 Structure inside Power Media Player Switch Timer 6.5 Cable entrance hole 3 cable entrance hole for A/C power cable, external power cable and LAN cable Cable entrance hole for LAN & Power cable Hisense B2B... -
Page 11: C Installation
7 A/C Installation 7.1 A/C Removal 7.1.1 Open the A/C door Unscrew remove cover here 7.1.2 Disconnect power cable to A/C 7.1.3 Take out A/C Turn down the rocker Hisense B2B... -
Page 12: Draw Out Tray And Take Out A/C
7.1.4 Draw out tray and take out A/C Tray 7.2 A/C installation 7.2.1 Put A/C in the tray and fix it by rocker Rocker 7.2.2 Connect power cable to A/C as below Hisense B2B... -
Page 13: Installation
8 Installation 8.1 Caution before installation 8.1.1 Installation Place & Environment This is floor standing mount, ensure the concrete must be solid and we propose custom concrete foundation. No less than 300mm No less than 1150mm to the rear Hisense B2B... -
Page 14: Custom Concrete Foundation
8.3 Lift product Use crane or other tool to lift up product to the concrete and align to installation hole in concrete, make sure the reserved cables pass through the entrance hole in base plate. Hisense B2B... - Page 15 Install washer and spring washer on bolt Spring washer Flat washer Step 3: take out 2 base plate cover in accessories and install it to hide installation hole Use screws to lock Install like this Base plate cover Hisense B2B...
-
Page 16: Power On Testing
After switch off, the display is inactive state, the default state is switch on, please shut down and switch off before maintenance Switch 9.2.3 Display status test The screen is in blue or playing content in normal condition and the internal fan start running. Hisense B2B... -
Page 17: Thermal Management
The product with air conditioner cooling, when inside temperature up to a certain degree the A/C will start working, please clean the mesh in air vent after long time running. 11 Media player Android media player (2G+16G) with HDMI IN port. 12 OS Android OS. Hisense B2B...
