Diagnostic LED:
System LED :
Per Port LED:
10/100/1000M TP Port 1 to 12
1000M SFP Fiber Port 11,12
Power Requirement
Voltage
Frequency
Consumption
Ambient Temperature
Humidity
Dimensions
Comply with FCC Part 15 Class A & CE Mark Approval
: LINK/ACT, 10/100/1000Mbps,
: SFP(LINK)
: AC Line
: 100∼240 V
: 50∼60 Hz
: Max. 15W ( in case no PD device connected)
Max. 135W ( with 8 x 15.4W PoE device connected )
Max. 185W ( with 12 x 15.4W PoE device connected )
: 0° to 50°C
: 5% to 90%
44(H) × 442(W) × 209(D) mm
:
227
User Manual
Power, CPU
PoE-PSE ACT, PoE FAIL
Publication date: May, 2005
Revision A1
