- Page 1 LevelOne GSW-0503T GSW-0803T 5/8-port Gigabit Switch User’s Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS INTRODUCTION ................1 ..................2 EATURES ..............2 ACKAGE ONTENTS HARDWARE DESCRIPTION............3 & R ..............3 RONT ANEL LED I ................4 NDICATORS INSTALLATION ................6 NETWORK APPLICATION............7 TECHNICAL SPECIFICATION ............8... -
Page 3: Introduction
This Technology will create high-speed backbone connections between switches, servers, database, and end stations. The GSW-0503T/0803T 5/8-Port Gigabit Switch is an ideal solution for solving traffic block at the core of the network. It offers 5/8 auto-negotiation 10/100/1000Base-T Gigabit Ethernet ports which can significantly improve your network backbone performance. -
Page 4: Features
Features Conforms to IEEE 802.3, 802.3u, 802.3ab and 802.3x 5 / 8-port 10/100/1000 Mbps Gigabit Switch Automatic MDI/MDIX crossover for all ports Back-plane: 5-port: 10Gbps back-plane 8-port: 16Gbps back-plane N-Way Auto-Negotiation Back pressure half duplex Flow control full duplex True non-blocking switching Store-and-Forward architecture support Package Contents One 5/8-Port Gigabit Switch... -
Page 5: Hardware Description
Hardware Description This Section describes the hardware of the 5/8-Port Gigabit Switch. Front & Rear Panel The Front Panel of the 5/8-Port Gigabit Switch consists of LED-indicators (100/1000, Link/Activity, Full duplex/Collision) for each Gigabit port and power LED-indicator for unit. Figure 2-1. -
Page 6: Led Indicators
Figure 2-2. The Rear Panel of the 5/8 Port Gigabit Switch LED Indicators The LED Indicators gives a real-time indication of system operating statuses. There are 3 LED-indicators (100/1000, LNK/ACT, FDX/COL) for The following table each Gigabit port and one Power LED for unit. provides descriptions of LEDs status and their meaning. - Page 7 No device attached or in 10Mbps mode Green The port is connecting with the device. LNK/ACT Blinking The port is receiving or transmitting data. No device attached. Orange The port is operating in Full-duplex mode. Blinking Packet collision occurred on this port. FDX/COL No device attached or in half-duplex mode.
-
Page 8: Installation
Installation This section shows the installation procedures of the switch. Set the Switch on a sufficiently large flat space with a power outlet nearby. The surface where you put your Switch should be clean, smooth, level, and sturdy. Make sure there is enough clearance around the Switch to allow attachment of cables, power cord and air circulation. -
Page 9: Network Application
Network Application This section provides you one sample of network topology in which the 5/8-Port Gigabit Switch is used. In general, the 5/8-Port Gigabit Switch is designed as a high-bandwidth backbone switch. You can use the 5/8-Port Gigabit Switch to connect servers, switches, workstation, and PCs (Of course, the Gigabit 1000Base-T NIC has installed into the PC) to each other by connecting these devices directly to the Switch. -
Page 10: Technical Specification
Technical Specification The following table provides the technical specification of 5/8 ports Gigabit Switch. IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet Standard IEEE 802.3ab Gigabit Ethernet IEEE802.3x Flow Control and Back-pressure Protocol CSMA/CD Technology Store-and-Forward switching architecture 14,880 pps for 10Mbps 148,800 pps for 100Mbps Transfer Rate 1,488,000 pps for 1000Mbps... - Page 11 Power Supply External power DC 12V/1.3A Power 5 port: 7.5 Watt (maximum) Consumption 8 port: 13.2Watt(maximum) Operation 0℃ to 45℃ (32℉ to 113℉) Temperature Operation 10% to 90% (Non-condensing) Humidity Dimension 165 x 100 x 32.5 mm (L x W x H) EMI &...
