LevelOne ProCon GSW-1290 Specifications

Datasheet_GSW-1290
4-port 1000T/mini GBIC + 2 expandable slots L2 SNMP Gigabit Switch
LevelOne's GSW-1290 is a high-capacity Master stackable SNMP
Layer 2 switch that provides reliable and expandible solutions for
large workgroups or backbones. When combined with MDU-1290M
and MDU-1290T modules for the two expansion slots, this device
acts as a stand alone switch with 12 Gigabit Ethernet ports,
supporting both copper and fibre connections. In addition, with 2
MDU-1290S 4-port stacking modules, this device performs as a
stacking master switch, and up to 12 GSW-2492 switches can be
stacked together in star architecture, providing 9.6Gbps of available
bandwidth and managed using a single IP address as a single
device. The entire switch stack is monitored through network or
console port on the GSW-1290.
The GSW-1290 supports a variety of network management features
including: Console, CLI, Telnet, Web, SNMP v1/v3, RMON, TFTP,
Port Mirroring and DHCP as well as advanced traffic management
options including: 802.1x, bandwidth control and support for IGMP
v1/v2 Snooping. In order to increase network reliablity, the switch
also supports 802.3ad, 802.1d and 802.1w standards.
With its 1U height rack-mountable size, the switch can be easily
managed in a computer lab or a server room. The clearly visible
status LEDs provide easy monitoring of port link activity, speed, and
collision, so that you are never in the dark when it comes to the
status of your data transmissions.
Back plane up to 24 Gbps
Master stacking with 12 GSW-2492 switches
in star topology to provide 288 10/100 Mbps
ports
12-port Gigabit Switch. With 4 built-in
10/100/1000Base-T ports (combo with 4 mini-
GBIC) and 2 expansion slots
Supports 802.1Q VLAN, GARP/GVRP, and
Asymmetric VLAN.
Supports Jumbo Frame (Up to 9216 bytes)
Key Features
802.1D compatible, 802.1w, 802.1s Spanning
Tree for redundant backup bridge paths
Supports SNMP management/ MIB
Supports 802.3ad LACP port trunks
Supports SNMP v.1, v.3 network management,
4 groups of RMON
802.1 port-based, MAC-based port access
control
Web-based management Interface
one world_one brand_one level_ one world_one brand_one level_
GSW-1290
